6
SE400
Series
Parts
Definition of Parts
Adjustable Trinocular Port
Threaded port with adjustable length of attachment of digital or video camera
Boom Stand
Stand for the microscope that allows the head to be moved in physical space in various directions
Continuous Zoom
A microscope head with a knob to change magnification through a range
Dimmer
Controls the amount of light that escapes from the illumination source
Diopter
Allows the focus to be perfected for both eyes, independent of each other
Fixed Power
Microscope head whose objectives are pre-set at certain levels and changed by rotating the objective
Focusing Knob
Used to move the microscope head vertically to bring the sample into focus
Frosted Glass Plate
A clear plate with frosted finish to provide a bottom light source for translucent samples
Gooseneck Illuminator
Illuminator independent of the unit that allows movement of one or two necks for controlled lighting
Head Lock Screw
Screws the microscope head into place
Magnification Knob
Changes the magnification of the lenses on a continuous zoom microscope
