SafeWizard Operating Instructions American Security Products Company
Last Revision 10/17/2008 Page 44 of 73 Document 4305199
Chapter 3-4-2-1
Factory Menus-
Locks & Doors-
Set Safe Locks
Only certain User Authority Levels will have access to this area.
3-4-2-1.1 Locks and Doors Menu
1 Set Safe Locks
2 Set Door Sensors
3 Set Entry Doors
4 Set Installed Doors
5 Setup Deposit Lock
QUIT back
Every aspect of door setup can be custom configured. In this Chapter
you will learn the various methods and steps required to complete
these tasks.
3-4-2-1.2 Locks and Doors Menu
Safe Lock Settings
Door 1
Door Type B/W w/s
Sol Act. Time 05
Door Open Time 090
Behind Door 00
BACK-NEXT Door
QUIT
Each safe door contains the same configuration options. Using the
NEXT and BACK keys toggles the doors, and UP and DOWN keys
navigate up or down through the options.
3-4-2-1.3 Locks and Doors Menu
Safe Lock Settings
Door 1
Door Type B/W w/s
Sol Act. Time 05
Door Open Time 090
Behind Door 00
BACK-NEXT Door
QUIT
The Sol Act. Time is the amount of time that the lock solenoid will
retain the bolt before locking the door again. The Door Open Time
configures the amount of time that a given door can be open before
going in to alarm, and the Behind Door indicates if this is a
subordinate door. (For example: Door 1 would have to be opened
before door 2 could be accessed.)
