Chapter-7: Application Macro
7-1 Fan Application
No Parameter Unit Def Min Max Description
A01-0 Acceleration
Time-1
Sec 10.0 0.1 6000.0
= 30 to 100 Sec. (30kw to 75 kw)
= 70 to 180 Sec. (90 kw & 200 kw)
= 100 to 250 Sec. (250 kw & above)
Note: Acceleration time should be in the range of 1/3 to
2/3 times of deceleration time settings.
A01-1 Deceleration
Time-1
Sec 20.0 0.1 6000.0
= 80 to 150 (30 kw to 75 kw)
= 150 to 250 (90 kw & 200 kw)
= 300 to 400 (250 kw & above)
C00-1 Run/stop method 2 1 2 Select coast to stop mode (C00-1=1), It is mandatory
when there is contactor or ACB in the output of the
drive.
C21-0 Number of retries 0 0 10 Allow restart 2 or 3 time in fault condition to continue fan
operation.
Note: Consult to customer before changing this
parameter as motor (load) will restart automatically in
case of tripping /power failure of VFD.
C04-D
PICK Peak-Up 0 -11 16 It is mandatory to enable speed search to start the VFD
at rotating speed of the motor as load is rotating for a
longer time due to load inertia to avoid any tripping while
restarting.
Take a start/stop trial with loaded motor at 4 different
rotating speeds (standstill, 5Hz, 20Hz, and 50 Hz) of the
actual rotor by keeping coast to stop & make sure that
rotating speed is caught by the VFD.
C21-2 Peak-Up wait time
Sec 2.0 0.5 10.0 Increase C21-2 If it not catching the rotating speed
B00-0 Rated input
voltage setting
(V/f control)
Vac 7 1 7 Select suitable rated input voltage from the below
selections.
B00-1 Max./base
frequency simple
setting
(V/f control)
1 0 9 Select the output frequency rating from the combination
below.
B00-2
Motor rated output
(V/f control)
Inverte
r rating
(kW)
0.10 750.00 The motor rated output at the base frequency is set.
B00-3 Motor rated output
(V/f control)
Vac 230.
or
400.
(V)
39 480 This is the Motor rated Voltage. Set the voltage
mentioned on the motor nameplate. The setting value
depends on the 400V, 500V or 600V Series model.
Value
200V system
400V system
1 to 200V to 380V
2 to 200V 381 to 400V
3 201 to 220V
401 to 415V
4 201 to 220V
416 to 440V
5 221 to 230V
441 to 460V
6 231 to 240V
461 to 480V
7 221 to 230V
381 to
Value Ftrq [Hz] Fmax [Hz]
0
Free setting on B00-4 and
B00-5
1 50 50
2 60 60
Value Ftrq [Hz] Fmax [Hz]
5 50 100
