Amtech
30
B00-0 Rated input
voltage setting
(V/f control)
Vac 7 1 7 Select suitable rated input voltage from the below
selections.
B00-1 Max./base
frequency simple
setting
(V/f control)
1 0 9 Select the output frequency rating from the combination
below.
B00-2
Motor rated output
(V/f control)
Inverte
r rating
(kW)
0.10 750.00 The motor rated output at the base frequency is set.
B00-3 Motor rated output
(V/f control)
Vac 230.
or
400.
(V)
39 480 This is the Motor rated Voltage. Set the voltage
mentioned on the motor nameplate. The setting value
depends on the 400V, 500V or 600V Series model.
B00-4
Max. frequency
(Fmax)
(V/f control)
50.00
(Hz)
Fbas
e or
3.00
Fbase
*7 or
440.0
0
When "B00-1" is a value other than 0, this will be
rewritten with the data set in the simple setting.
B00-5 Base frequency
(Fbase)
(V/f control)
50.00
(Hz)
Fmax/
7 or
1.00
Fmax
or
440.00
B00-6
Motor rated
current
(V/f control)
Invert
er
rating
(A)
Invert
er
rating
× 0.3
Inverte
r rating
This is the reference value for the over current limit,
OLT, current % display, analog input and output.
Note:
Speed Reference Selection: Enable below require parameter as per source of frequency reference
A00-0 – Local Set Frequency (Keypad of Axpert-VT240S)
C03-D to F – Frequency Reference Input (Analog I/O i.e. 0~10V, 4~20mA and others)
I/O's Requirements: Enable below parameter as per requirement.
C03-0 to C03-C and C13-0 to C13-6 for Digital I/O and C12-0 to C12-F and C14-0 to C14-B for Analog
I/O.
7-3 Pump Application
No Parameter Unit Def Min Max Description
A01-0 Acceleration
Time-1
Sec 10.0 0.1 6000.0 =10 to 15 seconds (5kw to 90kw).
=15 to 25 seconds (110kw and above rating).
A01-1 Deceleration
Time-1
Sec 20.0 0.1 6000.0 = 10 to 15 seconds (5kw to125kw).
= 15 to 25 seconds (110kw and above rating).
Value 200V system 400V system
1 to 200V to 380V
2 to 200V 381 to 400V
3 201 to 220V 401 to 415V
4 201 to 220V 416 to 440V
5 221 to 230V 441 to 460V
6 231 to 240V 461 to 480V
7 221 to 230V 381 to
400V
Value Ftrq [Hz] Fmax [Hz]
0
Free setting on B00-4 and
B00-5
1 50 50
2 60 60
3
50
60
4
50
75
Value Ftrq [Hz] Fmax [Hz]
5 50 100
6
60
70
7
60
80
8
60
90
9
60
120
