Start up Guide for Axpert-VT240S Series AC Drive
31
C00-1 Run/stop method 2 1 2 Select coast to stop mode (C00-1=1), It is mandatory
when there is contactor or ACB in the output of the
drive.
C21-0 Number of retries 0 0 10 Allow restart 1 time in fault condition to continue pump
operation.
Note: Consult to customer before changing this
parameter as motor (load) will restart automatically in
case of tripping /power failure of VFD.
B00-0 Rated input
voltage setting
(V/f control)
Vac 7 1 7 Select suitable rated input voltage from the below
selections.
B00-1 Max./base
frequency simple
setting
(V/f control)
1 0 9 Select the output frequency rating from the combination
below.
B00-2
Motor rated output
(V/f control)
Inverte
r rating
(kW)
0.10 750.00 The motor rated output at the base frequency is set.
B00-3 Motor rated output
(V/f control)
Vac 230.
or
400.
(V)
39 480 This is the Motor rated Voltage. Set the voltage
mentioned on the motor nameplate. The setting value
depends on the 400V, 500V or 600V Series model.
B00-4
Max. frequency
(Fmax)
(V/f control)
50.00
(Hz)
Fbas
e or
3.00
Fbase
*7 or
440.0
0
When "B00-1" is a value other than 0, this will be
rewritten with the data set in the simple setting.
B00-5 Base frequency
(Fbase)
(V/f control)
50.00
(Hz)
Fmax/
7 or
1.00
Fmax
or
440.00
B00-6
Motor rated
current
(V/f control)
Invert
er
rating
(A)
Invert
er
rating
× 0.3
Inverte
r rating
This is the reference value for the over current limit,
OLT, current % display, analog input and output.
Note:
Speed Reference Selection: Enable below require parameter as per source of frequency reference
A00-0 – Local Set Frequency (Keypad of Axpert-VT240S)
C03-D to F – Frequency Reference Input (Analog I/O i.e. 0~10V, 4~20mA and others)
I/O's Requirements: Enable below parameter as per requirement.
C03-0 to C03-C and C13-0 to C13-6 for Digital I/O and C12-0 to C12-F and C14-0 to C14-B for Analog
I/O.
Value
200V system
400V system
1 to 200V to 380V
2 to 200V 381 to 400V
3 201 to 220V
401 to 415V
4 201 to 220V
416 to 440V
5 221 to 230V
441 to 460V
6 231 to 240V
461 to 480V
7 221 to 230V
381 to
Value Ftrq [Hz] Fmax [Hz]
0
Free setting on B00-4 and
B00-5
1 50 50
2 60 60
Value Ftrq [Hz] Fmax [Hz]
5 50 100
To Next Page
