5. Insert lateral support T-bars into the seat back so that quick release levers
are facing outward and behind the seat post.
6. Insert the lateral supports into the T-bars and tighten the levers.
7. Use the seat post knob to adjust the height of the seat for your rider. Loosen
two turns and pull out on the knob. Adjust so that the spring loaded pin
pops into one of the holes in the seat post. Hand tighten the knob securely.
Quick release lever
Lateral support T-bar
NOTE: Lateral
supports are grooved
on the bottom and
slide into supports.
TIP: It is not necessary to remove the seat securing
knob; just loosen two turns and pull to release the
pin for adjustments.
.
