AMX AXCENT3 AND AXCENT3 PRO INTEGRATED AXCESS SYSTEM User Manual

Axcess Programming
15
Axcent
3
and Axcent
3
Pro Integrated Axcess Controllers
Send_Commands for the IR/Serial/Data Ports (Cont.)
SP
Generates a single
<IR out> function
pulse.
The CTON sets pulse length and CTOF sets time between pulses.
Syntax:
"’SP’,<IR out>"
Variables:
<IR out> = 1 - 127
Example:
SEND_COMMAND IR_1, "'SP',25"
Pulses IR code 25, which decreases the volume level on the equipment connected to
the controller.
XCH
Transmits the IR
code in the format
set with the XCHM
mode command.
Syntax:
’XCH [channel]’
Variables:
<channel> = 0 - 999
Mode 0 (default) Example:
SEND_COMMAND IR_1, 'XCH 3'
Transmits the IR code as 3 enter.
SEND_COMMAND IR_1, 'XCH 34 '
Transmits the IR code as 3 4 enter.
SEND_COMMAND IR_1, 'XCH 343 '
Transmits the IR code as 3 4 3 enter.
Mode 1 Example:
SEND_COMMAND IR_1,'XCH 3'
Transmits the IR code as 0 0 3 enter.
SEND_COMMAND IR_1, 'XCH 34'
Transmits the IR code as 0 3 4 enter.
SEND_COMMAND IR_1,'XCH 343'
Transmits the IR code as 3 4 3 enter.
Mode 2 Example:
SEND_COMMAND IR_1,'XCH 3'
Transmits the IR code as 0 0 3.
SEND_COMMAND IR_1,'XCH 34'
Transmits the IR code as 0 3 4.
SEND_COMMAND IR_1,'XCH 343'
Transmits the IR code as 3 4 3.
Mode 3 Example:
SEND_COMMAND IR_1,'XCH 3'
Transmits the IR code as 0 3.
SEND_COMMAND IR_1,'XCH 34'
Transmits the IR code as 3 4.
SEND_COMMAND IR_1,'XCH 343'
Transmits the IR code as 100 100 100 4 3.

AMX AXCENT3 AND AXCENT3 PRO INTEGRATED AXCESS SYSTEM Specifications

General

IR/Serial Ports	8
Relay Ports	8
I/O Ports	8
Ethernet	10/100 Mbps
Web Server	Yes
Operating Temperature	32° to 104° F (0° to 40° C)
Humidity	10% to 90% RH, non-condensing
