Enova DGX Dante™ Audio Switching Boards
135
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
Enova DGX 1600 Dante Audio Switching Board I/O and Dante Path Mapping
Dante ASB Input Board Dante ASB Output Board
Dante Subscription (EDGX-IN) Enova DGX ASB-DAN Input Enova DGX ASB-DAN Output Dante Subscription (EDGX-OUT)
Dante channels 01-LEFT,01-RIGHT Enova Stereo Audio Input 17 Enova Stereo Audio Output 17 Dante channels 01-LEFT,01-RIGHT
Dante channels 02-LEFT,02-RIGHT Enova Stereo Audio Input 18 Enova Stereo Audio Output 18 Dante channels 02-LEFT,02-RIGHT
Dante channels 03-LEFT,03-RIGHT Enova Stereo Audio Input 19 Enova Stereo Audio Output 19 Dante channels 03-LEFT,03-RIGHT
Dante channels 04-LEFT,04-RIGHT Enova Stereo Audio Input 20 Enova Stereo Audio Output 20 Dante channels 04-LEFT,04-RIGHT
Dante channels 05-LEFT,05-RIGHT Enova Stereo Audio Input 21 Enova Stereo Audio Output 21 Dante channels 05-LEFT,05-RIGHT
Dante channels 06-LEFT,06-RIGHT Enova Stereo Audio Input 22 Enova Stereo Audio Output 22 Dante channels 06-LEFT,06-RIGHT
Dante channels 07-LEFT,07-RIGHT Enova Stereo Audio Input 23 Enova Stereo Audio Output 23 Dante channels 07-LEFT,07-RIGHT
Dante channels 08-LEFT,08-RIGHT Enova Stereo Audio Input 24 Enova Stereo Audio Output 24 Dante channels 08-LEFT,08-RIGHT
Enova Audio Input 25 (Downmix)
Enova DGX 3200 Dante Audio Switching Board I/O and Dante Path Mapping
Dante ASB Input Board Dante ASB Output Board
Dante Subscription (EDGX-IN) Enova DGX ASB-DAN Input Enova DGX ASB-DAN Output Dante Subscription (EDGX-OUT)
Dante channels 01-LEFT,01-RIGHT Enova Stereo Audio Input 33 Enova Stereo Audio Output 33 Dante channels 01-LEFT,01-RIGHT
Dante channels 02-LEFT,02-RIGHT Enova Stereo Audio Input 34 Enova Stereo Audio Output 34 Dante channels 02-LEFT,02-RIGHT
Dante channels 03-LEFT,03-RIGHT Enova Stereo Audio Input 35 Enova Stereo Audio Output 35 Dante channels 03-LEFT,03-RIGHT
Dante channels 04-LEFT,04-RIGHT Enova Stereo Audio Input 36 Enova Stereo Audio Output 36 Dante channels 04-LEFT,04-RIGHT
Dante channels 05-LEFT,05-RIGHT Enova Stereo Audio Input 37 Enova Stereo Audio Output 37 Dante channels 05-LEFT,05-RIGHT
Dante channels 06-LEFT,06-RIGHT Enova Stereo Audio Input 38 Enova Stereo Audio Output 38 Dante channels 06-LEFT,06-RIGHT
Dante channels 07-LEFT,07-RIGHT Enova Stereo Audio Input 39 Enova Stereo Audio Output 39 Dante channels 07-LEFT,07-RIGHT
Dante channels 08-LEFT,08-RIGHT Enova Stereo Audio Input 40 Enova Stereo Audio Output 40 Dante channels 08-LEFT,08-RIGHT
Enova Audio Input 41 (Downmix)
Enova DGX 6400 Dante Audio Switching Board I/O and Dante Path Mapping
Dante ASB Input Board Dante ASB Output Board
Dante Subscription (EDGX-IN) Enova DGX ASB-DAN Input Enova DGX ASB-DAN Output Dante Subscription (EDGX-OUT)
Dante channels 01-LEFT,01-RIGHT Enova Stereo Audio Input 65 Enova Stereo Audio Output 65 Dante channels 01-LEFT,01-RIGHT
Dante channels 02-LEFT,02-RIGHT Enova Stereo Audio Input 66 Enova Stereo Audio Output 66 Dante channels 02-LEFT,02-RIGHT
Dante channels 03-LEFT,03-RIGHT Enova Stereo Audio Input 67 Enova Stereo Audio Output 67 Dante channels 03-LEFT,03-RIGHT
Dante channels 04-LEFT,04-RIGHT Enova Stereo Audio Input 68 Enova Stereo Audio Output 68 Dante channels 04-LEFT,04-RIGHT
Dante channels 05-LEFT,05-RIGHT Enova Stereo Audio Input 69 Enova Stereo Audio Output 69 Dante channels 05-LEFT,05-RIGHT
Dante channels 06-LEFT,06-RIGHT Enova Stereo Audio Input 70 Enova Stereo Audio Output 70 Dante channels 06-LEFT,06-RIGHT
Dante channels 07-LEFT,07-RIGHT Enova Stereo Audio Input 71 Enova Stereo Audio Output 71 Dante channels 07-LEFT,07-RIGHT
Dante channels 08-LEFT,08-RIGHT Enova Stereo Audio Input 72 Enova Stereo Audio Output 72 Dante channels 08-LEFT,08-RIGHT
Dante channels 09-LEFT,09-RIGHT Enova Stereo Audio Input 73 Enova Stereo Audio Output 73 Dante channels 09-LEFT,09-RIGHT
Dante channels 10-LEFT,10-RIGHT Enova Stereo Audio Input 74 Enova Stereo Audio Output 74 Dante channels 10-LEFT,10-RIGHT
Dante channels 11-LEFT,11-RIGHT Enova Stereo Audio Input 75 Enova Stereo Audio Output 75 Dante channels 11-LEFT,11-RIGHT
Dante channels 12-LEFT,12-RIGHT Enova Stereo Audio Input 76 Enova Stereo Audio Output 76 Dante channels 12-LEFT,12-RIGHT
Dante channels 13-LEFT,13-RIGHT Enova Stereo Audio Input 77 Enova Stereo Audio Output 77 Dante channels 13-LEFT,13-RIGHT
Dante channels 14-LEFT,14-RIGHT Enova Stereo Audio Input 78 Enova Stereo Audio Output 78 Dante channels 14-LEFT,14-RIGHT
Dante channels 15-LEFT,15-RIGHT Enova Stereo Audio Input 79 Enova Stereo Audio Output 79 Dante channels 15-LEFT,15-RIGHT
Dante channels 16-LEFT,16-RIGHT Enova Stereo Audio Input 80 Enova Stereo Audio Output 80 Dante channels 16-LEFT,16-RIGHT
Enova Audio Input 81 (Downmix)
