Product Overview and General Specifications
36
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
Compatibility and Hardware Support
System Compatibility Please refer to the shipping document:
Enova DGX Input/Output board and Endpoint
Compatibility Instructions
Requires kit v3.0.10 or later for new 100 Series
feature support. Older I/O cards added to a new
system must be upgraded.
I/O Board Hardware Support Supports Enova DGX HDMI, DVI, DXLink Twisted
Pair, DXLink Fiber Boards, and compatible Epica
DGX SC Optical Boards.
Does not support DXLink Twisted Pair 4K Boards or
4K HDMI Boards.
Supports all Enova DGX I/O boards.
Does not support Epica DGX SC Optical Boards.
Audio and EDID Functionality
EDID Read/Write Support Use DGX Configuration Software EDID Programmer
tab
Use System Configuration interface to change/
save/load EDID. Changes can be made to either
Video or Audio EDID or a Custom file loaded
Audio Expansion Boards
Only one type of Expansion Board
shall be used in a given enclosure.
Audio Insert/Extract (AIE) Boards Only • Audio Insert/Extract Boards (AIE)
• Audio Switching Boards (ASB)
NOTE: ASB must be installed as a pair.
Audio Insert/Extract/Routing AIE - DIP settings tie insertion/extraction to I/O
channels. No audio breakaway routing
AIE - DIP settings tie insertion/extraction to I/O
channels
ASB and ASB-DAN - Independent I/O channels
for audio switching, breakaway, and downmix.
Switched audio also supports DSP functionality.
Outputs utilizing ASB audio must be set to
SWITCHED audio.
Downmixing Not Supported Audio Switching Boards support one downmix
channel (the last audio input) which downmixes
any input channel and can be routed to any
output
Upgrades, Firmware Resets, and Default Restoration
Web Upgrade Status Web Control Interface link to status page
http://Master_IP_Address/web/upgrade/
systemUpgradeStatus.xml
System Configuration interface System/Devices
page, select the “Switcher Update Status”
button
Failed Upgrade Recovery Rolls back to previous kit version Completes the upgrade to attempted kit version
and identifies any mismatch in I/O cards that
failed to update. (This is shown in the OnLine
Tree, the System Configuration interface, and
DGX_SHELL> show.)
Factory Firmware Image Reset
Switcher
N/A DGX_SHELL> manage firmware then select
“F” for Factory
Factory Firmware Image Reset
Master and AxLink Controller
N/A ID Pushbutton on Master or Telnet to Master and
type: manage firmware then select the device
to reset (0 or 5001)
Restore system defaults BCS command (~def!)
• only resets MCPU
DGX_SHELL command (reset factory)
• resets whole system
System Components
RJ-45 ports Left: ENC & ENC
Right: Public LAN
Left: ICSLAN (Private LAN - DHCP Server)
Right: Public LAN
External MicroSD Card Contains system configuration, presets, eventlogs,
SRM file
• Contains no files or data
• Only for file transfer to/from Internal SD Card
Internal MicroSD Card N/A Contains sys configuration, eventlogs, SRM file,
current/previous/factory firmware, EDID Library
ID Button N/A • Use to change between DHCP/Static - 10 sec
hold while running
• Reset Factory (for Master) - 10 sec hold on
power up
• Factory Firmware Reset (for Master) - 20 sec
hold on power up
Integated AxLink Control N/A AxLink port for direct connection and control of
AxLink devices
Control Panel Basic control panel functions only Displays Integrated Master info and provides
basic audio support (for embedded audio only)
Enova DGX 100 Series and Enova DGX 8/16/32/64 Differences
