Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
4K HDMI CTA Video Information Code (VIC) Formats
NOTE: CTA VIC formats for HDMI Boards are located on page 67.
NOTE: The Short Video Descriptor (SVD) column describes the order of video preference.
NOTE: The Consumer Technology Association (CTA) was formerly known as the Consumer Electronics Association (CEA): the CEA
861 video standard has been renamed to CTA 861.
Audio Data Block
IMPORTANT: For information on troubleshooting audio, including a table on “Audio Format Support on Enova DGX Boards,” see
page 73.
SVD # VIC # Resolution Refresh Rate and Aspect Ratio Notes
001 VIC = 95 3840x2160p 29.97/30 Hz 16:9 HDMI VIC = 1
002 VIC = 94 3840x2160p 25 Hz 16:9 HDMI VIC = 2
003 VIC = 93 3840x2160p 23.98/24 Hz 16:9 HDMI VIC = 3
004 VIC = 100 4096x2160p 30 Hz 256:135
005 VIC = 98 4096x2160p 24 Hz 256:135 HDMI VIC = 4
006 VIC = 99 4096x2160p 25 Hz 256:135
007 VIC = 105 3840x2160p 30 Hz 64:27
008 VIC = 103 3840x2160p 24 Hz 64:27
009 VIC = 104 3840x2160p 25 Hz 64:27
010 VIC = 16 1920x1080p 59.94/60 Hz 16:9
011 VIC = 32 1920x1080p 23.97/24 Hz 16:9
012 VIC = 34 1920x1080p 29.97/30 Hz 16:9
013 VIC = 31 1920x1080p 50 Hz 16:9
014 VIC = 33 1920x1080p 25 Hz 16:9
015 VIC = 5 1920x1080i 59.94/60 Hz 16:9
016 VIC = 20 1920x1080i 50 Hz 16:9
017 VIC = 4 1280x720p 59.94/60 Hz 16:9
018 VIC = 3 720x480p 59.94/60 Hz 16:9
019 VIC = 19 1280x720p 50 Hz 16:9
020 VIC = 2 720x480p 59.94/60 Hz 4:3
021 VIC = 17 720x576p 50 Hz 4:3
022 VIC = 6 720(1440)x480i 59.94/60 Hz 4:3
023 VIC = 7 720(1440)x480i 59.94/60 Hz 16:9
024 VIC = 18 720x576p 50 Hz 16:9
025 VIC = 21 720(1440)x576i 50 Hz 4:3
026 VIC = 22 720(1440)x576i 50 Hz 16:9
027 VIC = 39 1920x1080i 50 Hz 16:9
028 VIC = 90 2560x1080p 60 Hz 64:27
029 VIC = 89 2560x1080p 50 Hz 64:27
030 VIC = 1 640x480p 59.94/60 Hz 4:3
Channels Sampling Frequency
Basic Audio: 2 channel L-PCM 32, 44.1, 48 kHz Sampling frequency at 16, 20, or 24 bits per sample
