Enova DGX DXLink™ Twisted Pair 4K Boards
98
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
3D Format Support Yes (Scaler on corresponding Output Board or RX must be set to Bypass mode)
• Frame Packing 1080p up to 24 Hz
• Frame Packing 720p up to 50/60 Hz
• Frame Packing 1080i up to 50/60 Hz
• Top-Bottom 1080p up to 24 Hz
• Top-Bottom 720p up to 50/60 Hz
• Side-by-Side Half 1080i up to 50/60 Hz
4K Resolution Support Yes
• 3840x2160p@24/25/30 Hz
• 4096x2160p@24/25/30 Hz
• 3840x2160p@60 Hz, 4:2:0*
• 4096x2160p@60 Hz, 4:2:0*
* Supported by DX-RX-4K when in Bypass Scaling mode.
NOTE: See full list of supported formats on page 99.
Audio Format Support • Dolby TrueHD, Dolby Digital, DTS-HD Master Audio, DTS, 2 CH through 8 CH L-PCM
(Dolby Digital and DTS support up to 48 kHz, 5.1 channels)
Audio Resolution 16 bit to 24 bit
Audio Sample Rate 32 kHz, 44.1 kHz, 48 kHz, 96 kHz, 192 kHz
Local Audio Support Yes, insertion and/or extraction of 2 CH L-PCM selectable by channel
Audio Switching Board Support Yes
• Supports break-away audio switching of 2 CH L-PCM for all channels
• Supports downmix from one input channel of Dolby True-HD, Dolby Digital, DTS-HD, DTS, or
2 to 8 channel L-PCM
EDID Support • EDID provided by Enova DGX Digital Media Switcher to the digital (HDMI) input on the DXLink
Transmitter
• EDID is user re-programmable
HDCP Support Yes, full matrix HDCP 1.4 support (includes any input to any or all outputs)
• Key Management System
• AMX HDCP InstaGate Pro® Technology
• Key support up to 16 destinations per output, independent of source device
CEC Support None
ICSP, TCP/IP, USB, IR, Serial, and
Control Management
Control Distribution is managed by the Enova DGX on-board NetLinx NX Master and Ethernet
Switch
USB (HID) Transport Use the Enova DGX Digital Media Switcher in conjunction with DXLink Transmitters and Receivers
(twisted pair and/or fiber), connect a DXLink Transmitter with HID hardware support to a PC and a
DXLink Receiver to a keyboard and mouse, the system then emulates commands from the receiver
back to the PC.
A list is available of HID devices which have been tested and found to work well with the latest
firmware (see “DXLink - HID Supported Devices” on the RX’s product page at
www.amx.com).
DXLink Twisted Pair Power DXLink Twisted Pair 4K Transmitters and Receivers can have power supplied over twisted pair cable
when connected to a DXLink Input or Output Board on the Enova DGX Digital Media Switcher
Input Board Propagation Delay 5 μs
Output Board Propagation Delay 5 μs
Connectors 4 RJ-45 ports
Twisted Pair Cable Type • Shielded Cat6A and Cat7
For more details and helpful cabling information, reference the white paper titled “Cabling for
Success with DXLink” available at
www.amx.com or contact your AMX representative.
Twisted Pair Cable Length Up to 262 ft. (80 m) for full 4K signal support.
Up to 328 ft. (100 m) for 1080p and below.
HDMI Cable Requirement HDMI High-Speed Cable Category 2 Required
Important Notice DXLink twisted pair cable runs for DXLink equipment shall only be run within a common building.
A “Common building” is defined as: Where the walls of the structure(s) are physically
connected and the structure(s) share a single ground reference.
Enova DGX DXLink Twisted Pair Board Specifications
