UG-1098 ADE9000 Technical Reference Manual
Rev. 0 | Page 54 of 86
Address Name Description Reset Access
Phase A current rms offset for the fundamental current rms, AIFRMS calculation.
0x014 AVFRMSOS Phase A voltage rms offset for the fundamental voltage rms, AVFRMS calculation. 0x00000000 R/W
0x015 AVRMSONEOS Phase A voltage rms offset for the fast RMS½ AVRMSONE calculation. 0x00000000 R/W
0x016 AIRMSONEOS Phase A current rms offset for the fast RMS½ AIRMSONE calculation. 0x00000000 R/W
0x017 AVRMS1012OS Phase A voltage rms offset for the 10 cycle rms/12 cycle rms AVRMS1012 calculation. 0x00000000 R/W
0x018 AIRMS1012OS Phase A current rms offset for the 10 cycle rms/12 cycle rms AIRMS1012 calculation. 0x00000000 R/W
0x020 BIGAIN Phase B current gain adjust. 0x00000000 R/W
0x021 BIGAIN0 Phase B multipoint gain correction factor. If multipoint gain and phase compensation
is enabled, with MTEN = 1 in the CONFIG0 register, an additional gain factor,
BIGAIN0 through BIGAIN5, is applied based on the BIRMS current rms amplitude
and the MTTHR_Lx and MTTHR_Hx register values.
0x00000000 R/W
Phase B multipoint gain correction factor. If multipoint gain and phase compensation
is enabled, with MTEN = 1 in the CONFIG0 register, an additional gain factor,
BIGAIN0 through BIGAIN5, is applied based on the BIRMS current rms amplitude
and the MTTHR_Lx and MTTHR_Hx register values.
0x023 BIGAIN2 Phase B multipoint gain correction factor. If multipoint gain and phase compensation
is enabled, with MTEN = 1 in the CONFIG0 register, an additional gain factor,
BIGAIN0 through BIGAIN5, is applied based on the BIRMS current rms amplitude
and the MTTHR_Lx and MTTHR_Hx register values.
0x00000000 R/W
0x024 BIGAIN3 Phase B multipoint gain correction factor. If multipoint gain and phase compensation
is enabled, with MTEN = 1 in the CONFIG0 register, an additional gain factor,
BIGAIN0 through BIGAIN5, is applied based on the BIRMS current rms amplitude
and the MTTHR_Lx and MTTHR_Hx register values.
0x00000000 R/W
0x025 BIGAIN4 Phase B multipoint gain correction factor. If multipoint gain and phase compensation
is enabled, with MTEN = 1 in the CONFIG0 register, an additional gain factor,
BIGAIN0 through BIGAIN5, is applied based on the BIRMS current rms amplitude
and the MTTHR_Lx and MTTHR_Hx register values.
0x00000000 R/W
0x026 BPHCAL0 Phase B multipoint phase correction factor. If multipoint phase and gain calibration is
disabled, with MTEN = 0 in the CONFIG0 register, the BPHCAL0 phase compensation
is applied. If multipoint phase and gain correction is enabled, with MTEN = 1, the
BPHCAL0 through BPHCAL4 value is applied based on the BIRMS current rms
amplitude and the MTTHR_Lx and MTTHR_Hx register values.
0x00000000 R/W
0x027 BPHCAL1 Phase B multipoint phase correction factor. If multipoint phase and gain calibration is
disabled, with MTEN = 0 in the CONFIG0 register, the BPHCAL0 phase compensation
is applied. If multipoint phase and gain correction is enabled, with MTEN = 1, the
BPHCAL0 through BPHCAL4 value is applied based on the BIRMS current rms
amplitude and the MTTHR_Lx and MTTHR_Hx register values.
0x00000000 R/W
0x028 BPHCAL2 Phase B multipoint phase correction factor. If multipoint phase and gain calibration is
disabled, with MTEN = 0 in the CONFIG0 register, the BPHCAL0 phase compensation
is applied. If multipoint phase and gain correction is enabled, with MTEN = 1, the
BPHCAL0 through BPHCAL4 value is applied based on the BIRMS current rms
amplitude and the MTTHR_Lx and MTTHR_Hx register values.
0x00000000 R/W
Phase B multipoint phase correction factor. If multipoint phase and gain calibration is
disabled, with MTEN = 0 in the CONFIG0 register, the BPHCAL0 phase compensation
is applied. If multipoint phase and gain correction is enabled, with MTEN = 1, the
BPHCAL0 through BPHCAL4 value is applied based on the BIRMS current rms
amplitude and the MTTHR_Lx and MTTHR_Hx register values.
0x02A BPHCAL4 Phase B multipoint phase correction factor. If multipoint phase and gain calibration is
disabled, with MTEN = 0 in the CONFIG0 register, the BPHCAL0 phase compensation
is applied. If multipoint phase and gain correction is enabled, with MTEN = 1, the
BPHCAL0 through BPHCAL4 value is applied based on the BIRMS current rms
amplitude and the MTTHR_Lx and MTTHR_Hx register values.
0x00000000 R/W
0x02B BVGAIN Phase B voltage gain adjust. 0x00000000 R/W
0x02C BIRMSOS Phase B current rms offset for the BIRMS calculation. 0x00000000 R/W
0x02D BVRMSOS Phase B voltage rms offset for the BVRMS calculation. 0x00000000 R/W
0x02E BPGAIN Phase B power gain adjust for the BWATT, BVA, BVAR, BFWATT, BFVA, and BFVAR
calculations.
0x00000000 R/W
0x02F BWATTOS Phase B total active power offset correction for the BWATT calculation. 0x00000000 R/W
