ADE9000 Technical Reference Manual UG-1098

Rev. 0 | Page 55 of 86

Address Name Description Reset Access

0x030

BVAROS

Phase B total reactive power offset correction for the BVAR calculation.

0x00000000

R/W

0x031 BFWATTOS Phase B fundamental active power offset correction for the BFWATT calculation. 0x00000000 R/W

0x032 BFVAROS Phase B fundamental reactive power offset correction for the BFVAR calculation. 0x00000000 R/W

0x033 BIFRMSOS Phase B current rms offset for the fundamental current rms BIFRMS calculation. 0x00000000 R/W

0x034 BVFRMSOS Phase B voltage rms offset for the fundamental voltage rms BVFRMS calculation. 0x00000000 R/W

0x035 BVRMSONEOS Phase B voltage rms offset for the fast RMS½ BVRMSONE calculation. 0x00000000 R/W

0x036 BIRMSONEOS Phase B current rms offset for the fast RMS½ BIRMSONE calculation. 0x00000000 R/W

0x037 BVRMS1012OS Phase B voltage rms offset for the 10 cycle rms/12 cycle rms BVRMS1012 calculation. 0x00000000 R/W

0x038 BIRMS1012OS Phase B current rms offset for the 10 cycle rms/12 cycle rms BVRMS1012 calculation. 0x00000000 R/W

0x040 CIGAIN Phase C current gain adjust. 0x00000000 R/W

0x041 CIGAIN0 Phase C multipoint gain correction factor. If multipoint gain and phase compensation

is enabled, with MTEN = 1 in the CONFIG0 register, an additional gain factor,

CIGAIN0 through CIGAIN5, is applied based on the CIRMS current rms amplitude

and the MTTHR_Lx and MTTHR_Hx register values.

0x00000000 R/W

0x042 CIGAIN1 Phase C multipoint gain correction factor. If multipoint gain and phase compensation

is enabled, with MTEN = 1 in the CONFIG0 register, an additional gain factor,

CIGAIN0 through CIGAIN5, is applied based on the CIRMS current rms amplitude

and the MTTHR_Lx and MTTHR_Hx register values.

0x00000000 R/W

0x043 CIGAIN2 Phase C multipoint gain correction factor. If multipoint gain and phase compensation

is enabled, with MTEN = 1 in the CONFIG0 register, an additional gain factor,

CIGAIN0 through CIGAIN5, is applied based on the CIRMS current rms amplitude

and the MTTHR_Lx and MTTHR_Hx register values.

0x00000000 R/W

0x044 CIGAIN3 Phase C Multipoint gain correction factor. If multipoint gain and phase compensation

is enabled, with MTEN = 1 in the CONFIG0 register, an additional gain factor,

CIGAIN0 through CIGAIN5, is applied based on the CIRMS current rms amplitude

and the MTTHR_Lx and MTTHR_Hx register values.

0x00000000 R/W

0x045 CIGAIN4 Phase C Multipoint gain correction factor. If multipoint gain and phase compensation

is enabled, with MTEN = 1 in the CONFIG0 register, an additional gain factor,

CIGAIN0 through CIGAIN5, is applied based on the CIRMS current rms amplitude

and the MTTHR_Lx and MTTHR_Hx register values.

0x00000000 R/W

0x046 CPHCAL0 Phase C multipoint phase correction factor. If multipoint phase and gain calibration is
