UG-1098 ADE9000 Technical Reference Manual

Rev. 0 | Page 56 of 86

Address Name Description Reset Access

0x04E

CPGAIN

Phase C power gain adjust for the CWATT, CVA, CVAR, CFWATT, CFVA, and CFVAR

calculations.

0x00000000

R/W

0x04F CWAT TOS Phase C total active power offset correction for the CWATT calculation. 0x00000000 R/W

0x050 CVAROS Phase C total reactive power offset correction for the CVAR calculation. 0x00000000 R/W

0x051 CFWATTOS Phase C fundamental active power offset correction for the CFWATT calculation. 0x00000000 R/W

0x052 CFVAROS Phase C fundamental reactive power offset correction for the CFVAR calculation. 0x00000000 R/W

0x053 CIFRMSOS Phase C current rms offset for the fundamental current rms CIFRMS calculation. 0x00000000 R/W

0x054 CVFRMSOS Phase C voltage rms offset for the fundamental voltage rms CVFRMS calculation. 0x00000000 R/W

0x055 CVRMSONEOS Phase C voltage rms offset for the fast RMS½ CVRMSONE calculation. 0x00000000 R/W

0x056 CIRMSONEOS Phase C current rms offset for the fast RMS½ CIRMSONE calculation. 0x00000000 R/W

0x057 CVRMS1012OS Phase C voltage rms offset for the 10 cycle rms/12 cycle rms CVRMS1012 calculation. 0x00000000 R/W

0x058 CIRMS1012OS Phase C current rms offset for the 10 cycle rms/12 cycle rms CIRMS1012 calculation. 0x00000000 R/W

0x060 CONFIG0 Configuration Register 0. 0x00000000 R/W

0x061 MTTHR_L0 Multipoint phase/gain threshold. If MTEN = 1 in the CONFIG0 register, the

MTGNTHR_Lx and MTGNTHR_Hx registers set up the ranges in which to apply

each set of corrections, allowing hysteresis. See the Multipoint Phase/Gain

Calibration section for more information.

0x00000000 R/W

0x062 MTTHR_L1 Multipoint phase/gain threshold. See MTTHR_L0 for more information. 0x00000000 R/W

0x063 MTTHR_L2 Multipoint phase/gain threshold. See MTTHR_L0 for more information. 0x00000000 R/W

0x064 MTTHR_L3 Multipoint phase/gain threshold. See MTTHR_L0 for more information. 0x00000000 R/W

0x065 MTTHR_L4 Multipoint phase/gain threshold. See MTTHR_L0 for more information. 0x00000000 R/W

0x066 MTTHR_H0 Multipoint phase/gain threshold. See MTTHR_L0 for more information. 0x00000000 R/W

0x067 MTTHR_H1 Multipoint phase/gain threshold. See MTTHR_L0 for more information. 0x00000000 R/W

0x068 MTTHR_H2 Multipoint phase/gain threshold. See MTTHR_L0 for more information. 0x00000000 R/W

0x069 MTTHR_H3 Multipoint phase/gain threshold. See MTTHR_L0 for more information. 0x00000000 R/W

0x06A MTTHR_H4 Multipoint phase/gain threshold. See MTTHR_L0 for more information. 0x00000000 R/W

0x06B NIRMSOS Neutral current rms offset for the NIRMS calculation. 0x00000000 R/W

0x06C ISUMRMSOS Offset correction for the ISUMRMS calculation based on the sum of IA + IB + IC ± IN. 0x00000000 R/W

0x06D

NIGAIN

Neutral current gain adjust.

0x00000000

R/W

0x06E NPHCAL Neutral current phase compensation. 0x00000000 R/W

0x06F NIRMSONEOS Neutral current rms offset for the fast RMS½ NIRMSONE calculation. 0x00000000 R/W

0x070 NIRMS1012OS Neutral current rms offset for the 10 cycle rms/12 cycle rms NIRMS1012 calculation. 0x00000000 R/W

0x071 VNOM Nominal phase voltage rms used in the computation of apparent power, xVA,

when the VNOMx_EN bit is set in the CONFIG0 register.

0x00000000 R/W

0x072 DICOEFF Value used in the digital integrator algorithm. If the integrator is turned on, with

INTEN or ININTEN equal to one in the CONFIG0 register, it is recommended to set

this value to 0xFFFFE000.

0x00000000 R/W

0x073 ISUMLVL Threshold to compare ISUMRMS against. Configure this register to receive a

MISMTCH indication in STATUS0 if ISUMRMS exceeds this threshold.

0x00000000 R/W

0x20A AI_PCF Instantaneous Phase A current channel waveform processed by the DSP at 8 kSPS. 0x00000000 R

0x20B AV_PCF Instantaneous Phase A voltage channel waveform processed by the DSP at 8 kSPS. 0x00000000 R

0x20C AIRMS Phase A filter-based current rms value, updates at 8 kSPS. 0x00000000 R

0x20D AVRMS Phase A filter-based voltage rms value, updates at 8 kSPS. 0x00000000 R

0x20E AIFRMS Phase A current fundamental rms, updates at 8 kSPS. 0x00000000 R

0x20F AVFRMS Phase A voltage fundamental RMS, updates at 8 kSPS. 0x00000000 R

0x210 AWAT T Phase A low-pass filtered total active power, updated at 8 kSPS. 0x00000000 R

0x211 AVAR Phase A low-pass filtered total reactive power, updated at 8 kSPS. 0x00000000 R

0x212 AVA Phase A total apparent power, updated at 8 kSPS. 0x00000000 R

0x213 AFWAT T Phase A fundamental active power, updated at 8 kSPS. 0x00000000 R

0x214 AFVAR Phase A fundamental reactive power, updated at 8 kSPS. 0x00000000 R

0x215 AFVA Phase A fundamental apparent power, updated at 8 kSPS. 0x00000000 R

0x216 APF Phase A power factor, updated every 1.024 sec. 0x00000000 R

0x217 AVTHD Phase A voltage THD, updated every 1.024 sec. 0x00000000 R
