ADE9000 Technical Reference Manual UG-1098
Rev. 0 | Page 57 of 86
Address Name Description Reset Access
Phase A current THD, updated every 1.024 sec.
0x219 AIRMSONE Phase A current fast RMS½ calculation, one cycle rms updated every half cycle. 0x00000000 R
0x21A AVRMSONE Phase A voltage fast RMS½ calculation, one cycle rms updated every half cycle. 0x00000000 R
0x21B AIRMS1012 Phase A current fast 10 cycle rms/12 cycle rms calculation. The calculation is
performed over 10 cycles if SELFREQ = 0 for a 50 Hz network or over 12 cycles if
SELFREQ = 1 for a 60 Hz network, in the ACCMODE register.
0x00000000 R
0x21C AVRMS1012 Phase A voltage fast 10 cycle rms/12 cycle rms calculation. The calculation is
performed over 10 cycles if SELFREQ = 0 for a 50 Hz network or over 12 cycles if
SELFREQ = 1 for a 60 Hz network, in the ACCMODE register.
0x00000000 R
0x21D AMTREGION If multipoint gain and phase compensation is enabled, with MTEN = 1 in the
CONFIG0 register, this register indicate which AIGAINx and APHCALx is currently
being used.
0x0000000F R
0x22A BI_PCF Instantaneous Phase B current channel waveform processed by the DSP at 8 kSPS. 0x00000000 R
0x22B BV_PCF Instantaneous Phase B voltage channel waveform processed by the DSP at 8 kSPS. 0x00000000 R
0x22C BIRMS Phase B filter-based current rms value, updates at 8 kSPS. 0x00000000 R
0x22D BVRMS Phase B filter-based voltage rms value, updates at 8 kSPS. 0x00000000 R
0x22E BIFRMS Phase B current fundamental rms, updates at 8 kSPS. 0x00000000 R
0x22F BVFRMS Phase B voltage fundamental rms, updates at 8 kSPS. 0x00000000 R
0x230 BWAT T Phase B low-pass filtered total active power, updated at 8 kSPS. 0x00000000 R
0x231 BVAR Phase B low-pass filtered total reactive power, updated at 8 kSPS. 0x00000000 R
0x232 BVA Phase B total apparent power, updated at 8 kSPS. 0x00000000 R
0x233 BFWATT Phase B fundamental active power, updated at 8 kSPS. 0x00000000 R
0x234 BFVAR Phase B fundamental reactive power, updated at 8 kSPS. 0x00000000 R
0x235 BFVA Phase B fundamental apparent power, updated at 8 kSPS. 0x00000000 R
0x236 BPF Phase B power factor, updated every 1.024 sec. 0x00000000 R
0x237 BVTHD Phase B voltage THD, updated every 1.024 sec. 0x00000000 R
0x238 BITHD Phase B current THD, updated every 1.024 sec. 0x00000000 R
0x239 BIRMSONE Phase B current fast RMS½ calculation, one cycle rms updated every half cycle. 0x00000000 R
Phase B voltage fast RMS½ calculation, one cycle rms updated every half cycle.
0x23B BIRMS1012 Phase B current fast 10 cycle rms/12 cycle rms calculation. The calculation is
performed over 10 cycles if SELFREQ = 0 for a 50 Hz network or over 12 cycles if
SELFREQ = 1 for a 60 Hz network, in the ACCMODE register.
0x00000000 R
0x23C BVRMS1012 Phase B voltage fast 10 cycle rms/12 cycle rms calculation. The calculation is
performed over 10 cycles if SELFREQ = 0 for a 50 Hz network or over 12 cycles if
SELFREQ = 1 for a 60 Hz network, in the ACCMODE register.
0x00000000 R
0x23D BMTREGION If multipoint gain and phase compensation is enabled, with MTEN = 1 in the COFIG0
register, this register indicate which BIGAINx and BPHCALx is currently being used.
0x0000000F R
0x24A CI_PCF Instantaneous Phase C current channel waveform processed by the DSP at 8 kSPS. 0x00000000 R
0x24B CV_PCF Instantaneous Phase C voltage channel waveform processed by the DSP at 8 kSPS. 0x00000000 R
0x24C CIRMS Phase C filter-based current rms value, updates at 8 kSPS. 0x00000000 R
0x24D CVRMS Phase C filter-based voltage rms value, updates at 8 kSPS. 0x00000000 R
0x24E CIFRMS Phase C current fundamental rms, updates at 8 kSPS. 0x00000000 R
0x24F CVFRMS Phase C voltage fundamental rms, updates at 8 kSPS. 0x00000000 R
0x250 CWATT Phase C low-pass filtered total active power, updated at 8 kSPS. 0x00000000 R
0x251 CVAR Phase C low-pass filtered total reactive power, updated at 8 kSPS. 0x00000000 R
Phase C total apparent power, updated at 8 kSPS.
0x253 CFWATT Phase C fundamental active power, updated at 8 kSPS. 0x00000000 R
0x254 CFVAR Phase C fundamental reactive power, updated at 8 kSPS. 0x00000000 R
0x255 CFVA Phase C fundamental apparent power, updated at 8 kSPS. 0x00000000 R
0x256 CPF Phase C power factor, updated every 1.024 sec. 0x00000000 R
0x257 CVTHD Phase C voltage THD, updated every 1.024 sec. 0x00000000 R
0x258 CITHD Phase C current total THD, updated every 1.024 sec. 0x00000000 R
0x259 CIRMSONE Phase C current fast RMS½ calculation, one cycle rms updated every half cycle. 0x00000000 R
