Analog Devices ADE9000 User Manual

UG-1098 ADE9000 Technical Reference Manual
Rev. 0 | Page 76 of 86
Addr. Name Bits Bit Name Settings Description Reset Access
0x410 DIP_LVL [31:24] RESERVED Reserved. 0x0 R
[23:0] DIPLVL Voltage RMS½ dip detection threshold level. 0x0 R/W
0x411 DIPA [31:24] RESERVED Reserved. 0x0 R
[23:0] DIPA_VAL Phase A voltage RMS½ value during a dip
condition.
0x7FFFFF R
0x412 DIPB [31:24] RESERVED Reserved. 0x0 R
[23:0]
DIPB_VAL
Phase B voltage RMS½ value during a dip
condition.
0x7FFFFF
R
0x413 DIPC [31:24] RESERVED Reserved. 0x0 R
[23:0] DIPC_VAL Phase C voltage RMS½ value during a dip
condition.
0x7FFFFF R
0x414 SWELL_LVL [31:24] RESERVED Reserved. 0x0 R
[23:0] SWELLLVL Voltage RMS½ swell detection threshold level. 0xFFFFFF R/W
0x415 SWELLA [31:24] RESERVED Reserved. 0x0 R
[23:0] SWELLA_VAL Phase A voltage RMS½ value during a swell
condition.
0x0 R
0x416 SWELLB [31:24] RESERVED Reserved. 0x0 R
[23:0] SWELLB_VAL Phase B voltage RMS½ value during a swell
condition.
0x0 R
0x417 SWELLC [31:24] RESERVED Reserved. 0x0 R
[23:0] SWELLC_VAL Phase C voltage RMS½ value during a swell
condition.
0x0 R
0x41F PHNOLOAD [31:18] RESERVED Reserved. 0x0 R
17 CFVANL This bit is set if the Phase C fundamental
apparent energy is in no load.
0x0 R
16 CFVARNL
This bit is set if the Phase C fundamental reactive
energy is in no load.
0x0 R
15 CFWATTNL This bit is set if the Phase C fundamental active
energy is in no load.
0x0 R
14
CVANL
This bit is set if the Phase C total apparent
energy is in no load.
0x0
R
13 CVARNL This bit is set if the Phase B total reactive energy
is in no load.
0x0 R
12 CWAT TNL This bit is set if the Phase C total active energy is
in no load.
0x0 R
11 BFVANL This bit is set if the Phase B fundamental
apparent energy is in no load.
0x0 R
10 BFVARNL
This bit is set if the Phase B fundamental reactive
energy is in no load.
0x0 R
9
BFWAT TNL
This bit is set if the Phase B fundamental active
energy is in no load.
0x0
R
8 BVANL This bit is set if the Phase B total apparent
energy is in no load.
0x0 R
7 BVARNL This bit is set if the Phase B total reactive energy
is in no load.
0x0 R
6 BWATTNL This bit is set if the Phase B total active energy is
in no load.
0x0 R
5 AFVANL This bit is set if the Phase A fundamental
apparent energy is in no load.
0x0 R
4 AFVARNL
This bit is set if the Phase A fundamental reactive
energy is in no load.
0x0 R
3 AFWAT TNL This bit is set if the Phase A fundamental active
energy is in no load.
0x0 R
