Analog Devices ADE9000 User Manual

ADE9000 Technical Reference Manual UG-1098
Rev. 0 | Page 77 of 86
Addr. Name Bits Bit Name Settings Description Reset Access
2
AVANL
This bit is set if the Phase A total apparent
energy is in no load.
0x0
R
1 AVARNL This bit is set if the Phase A total reactive energy
is in no load.
0x0 R
0 AWAT TNL This bit is set if the Phase A total active energy is
in no load.
0x0 R
0x424 ADC_REDIRECT [31:21] RESERVED Reserved. 0x0 R
[20:18] VC_DIN VC channel data can be selected from all channels.
The bit descriptions for 000b through 110b match
VC_DIN. When the value is equal to 111b, then
0x7 R/W
000 IA ADC data.
001 IB ADC data.
010 IC ADC data.
011 IN ADC data.
100 VA ADC data.
101 VB ADC data.
110 VC ADC data.
111
VC ADC data.
[17:15] VB_DIN VB channel data can be selected from all channels.
The bit descriptions for 000b through 110b match
VC_DIN. When the value is equal to 111b, then
0x7 R/W
111
VB ADC data.
[14:12] VA_DIN VA channel data can be selected from all channels.
The bit descriptions for 000b through 110b match
VC_DIN. When the value is equal to 111b, then
0x7 R/W
111
VA ADC data.
[11:9] IN_DIN IN channel data can be selected from all channels.
The bit descriptions for 000b through 110b match
VC_DIN. When the value is equal to 111b, then
0x7 R/W
111 IN ADC data.
[8:6] IC_DIN IC channel data can be selected from all channels.
The bit descriptions for 000b through 110b match
VC_DIN. When the value is equal to 111b, then
0x7 R/W
111 IC ADC data.
[5:3] IB_DIN IB channel data can be selected from all channels.
The bit descriptions for 000b through 110b match
VC_DIN. When the value is equal to 111b, then
0x7 R/W
111 IB ADC data.
[2:0] IA_DIN IA channel data can be selected from all channels.
The bit descriptions for 000b through 110b match
VC_DIN. When the value is equal to 111b, then
0x7 R/W
111 IA ADC data.
