Analog Devices ADE9000 User Manual

UG-1098 ADE9000 Technical Reference Manual
Rev. 0 | Page 84 of 86
Addr. Name Bits Bit Name Settings Description Reset Access
6
PWR_SIGN_SEL[0]
Selects whether the REVAPx bit follows the sign
of the total or fundamental active power.
0x0
R/W
0 Total active power.
1 Fundamental active power.
5 RD_RST_EN Set this bit to enable the energy register read
with reset feature. If this bit is set, when one of
the xWATTHR, xVAHR, xVARH, xFWATTHR,
xFVAHR, and xFVARHR register is read, it is reset
and begins accumulating energy from zero.
0x0 R/W
4 EGY_LD_ACCUM If this bit is equal to zero, the internal energy
register is added to the user accessible energy
register. If the bit is set, the internal energy
register overwrites the user accessible energy
register when the EGYRDY event occurs.
0x0 R/W
[3:2] RESERVED Reserved. 0x0 R
1 EGY_TMR_MODE This bit determines whether energy is
accumulated based on the number of 8 kSPS
samples or zero-crossing events configured in
the EGY_TIME register.
0x0 R/W
0 Accumulate energy based on 8 kSPS samples.
1 Accumulate energy based on the zero-crossing
selected by the ZX_SEL bits in the ZX_LP_SEL
register.
0 EGY_PWR_EN Set this bit to enable the energy and power
accumulator, when the run bit is also set.
0x0 R/W
0x4B4
CRC_FORCE
[15:1]
RESERVED
Reserved.
0x0
R
0 FORCE_CRC_UPDATE Write this bit to force the configuration register
CRC calculation to start. When the calculation is
complete, the CRC_DONE bit is set in the
STATUS1 register.
0x0 R/W
0x4B5 CRC_OPTEN 15 CRC_WFB_TRG_CFG_EN
Set this bit to include the WFB_TRG_CFG register
in the configuration register CRC calculation.
0x0 R/W
14
CRC_WFB_PG_IRQEN
Set this bit to include the WFB_PG_IRQEN register
in the configuration register CRC calculation.
0x0
R/W
13 CRC_WFB_CFG_EN Set this bit to include the WFB_CFG register in
the configuration register CRC calculation.
0x0 R/W
12 CRC_SEQ_CYC_EN Set this bit to include the SEQ_CYC register in
the configuration register CRC calculation.
0x0 R/W
11 CRC_ZXLPSEL_EN Set this bit to include the ZX_LP_SEL register in
the configuration register CRC calculation.
0x0 R/W
10 CRC_ZXTOUT_EN Set this bit to include the CRC_ZXTOUT_EN register
in the configuration register CRC calculation.
0x0 R/W
9 CRC_APP_NL_LVL_EN
Set this bit to include the APP_NL_LVL register in
the configuration register CRC calculation.
0x0 R/W
8 CRC_REACT_NL_LVL_EN Set this bit to include the REACT_NL_LVL register in
the configuration register CRC calculation.
0x0 R/W
7 CRC_ACT_NL_LVL_EN
Set this bit to include the ACT_NL_LVL register in
the configuration register CRC calculation.
0x0 R/W
6 CRC_SWELL_CYC_EN Set this bit to include the SWELL_CYC register in
the configuration register CRC calculation.
0x0 R/W
5 CRC_SWELL_LVL_EN Set this bit to include the SWELL_LVL register in
the configuration register CRC calculation.
0x0 R/W
4 CRC_DIP_CYC_EN Set this bit to include the DIP_CYC register in the
configuration register CRC calculation.
0x0 R/W
3 CRC_DIP_LVL_EN
Set this bit to include the DIP_LVL register in the
configuration register CRC calculation.
0x0 R/W
