EVAL-ADAU1467Z UG-1134
Rev. A (Draft) | Page 51 of 55
ORDERING INFORMATION
BILL OF MATERIALS
Table 7.
Qty Reference Designator Description Manufacturer Part Number
48 C1, C3 to C7, C9, C11, C12,
C14, C17, C20, C22, C24, C26,
C27 to C29, C40, C41, C43,
C45, C47, C50, C52, C55 to
C60, C64, C65, C72, C75 to
C77, C90, C92, C97, C98,
C112, C114, C119, C122,
C128, C133, C134
Multilayer ceramic capacitors, 16 V, X7R
(0402), 0.10 µF
Murata ENA GRM155R71C104KA88D
2 C100, C101 Aluminum electrolytic capacitors, 105°C,
SMD_B, 10 µF
Panasonic EC EEE-FC1C100R
2 C129, C130 Multilayer ceramic capacitors, 16 V, X7R
(0603), 1.0 µF
Murata ENA GRM188R71C105KA12D
26 C13, C18, C46, C51, C61 to
C63, C71, C74, C86, C88, C91,
C93, C95, C99, C102, C113,
C115, C117, C121, C124,
C135 to C139
Multilayer ceramic capacitors, 10 V, X7R
(0805), 10 µF
Murata ENA GRM21BR71A106KE51L
2 C131, C132 Aluminum electrolytic capacitors, 105°C,
100 µF
Panasonic EC EEE-FC1C101P
4 C15, C16, C42, C44 Multilayer ceramic capacitors, 25 V, X7R
(0402), 10 nF
Murata GRM155R71E103JA01J
2 C19, C49 Multilayer ceramic capacitors, 25 V, NP0
(0402), 5.6 nF
Murata GRM155R71E562KA01D
1 C2 Tantalum capacitor, 105°C, 47 µF Kemet T520B476M010ATE035
1 C21 Multilayer ceramic capacitor, 50 V, NP0
(0402), 150 pF
Murata ENA GRM1555C1H151JA01D
Ceramic capacitor, 6.3 V, X7R, 1210, 47.0 µF
8 C30, C33, C36, C53, C89,
C96, C118, C127
Multilayer ceramic capacitors, 50 V, NP0
(0402), 100 pF
Murata ENA GRM1555C1H101JA01D
8 C31, C32, C34, C35, C37 to
C39, C54
Multilayer ceramic capacitors, 50 V, NP0
(0402), 1.0 nF
Murata ENA GRM1555C1H102JA01D
1 C48 Multilayer ceramic capacitor, 50 V, NP0
(0402), 390 pF
Murata ENA GRM1555C1H391JA01D
16 C66 to C68, C73, C79, C80
to C82, C103 to C105, C109
to C111, C120, C125
Multilayer ceramic capacitors, 50 V, NP0
(0402), 33 pF
Murata ENA GRM1555C1H330JA01D
8 C69, C70, C78, C85, C106 to
C108, C123
Multilayer ceramic capacitors, 50 V, NP0
(0402), 82 pF
Murata ENA GRM1555C1H820JA01D
2 C8, C10 Multilayer ceramic capacitors, 50 V, NP0
(0402), 22 pF
Murata ENC GRM1555C1H220JA01D
2 C83, C84 Aluminum electrolytic capacitors, FC, 105°C,
SMD_D, 47 µF
Panasonic EC EEE-FC1C470P
4 C87, C94, C116, C126 Multilayer ceramic capacitors, 50 V, NP0
(0402), 330 pF
Murata ENA GRM1555C1H331JA01D
9 D1 to D9 LED, 3 millicandela, 571 nm, 0603, green Lite-On LTST-C191KGKT
2 J1, J6 10-way shroud polarized headers, 2 × 5 3M N2510-6002RB
1 J10 TOSLINK, 16 Mpbs, optical receiver,
PLR135/T10
Everlight Americas PLR135/T10
1 J11 120-pin header, 0.6 mm Hirose Electric FX8-120P-SV1(91)
6 J12 to J15, J17, J18 Stereo mini jacks, SMT, SJ-3523-SMT CUI Inc. SJ-3523-SMT
1 J16 Mini power jack, 0.08 inch Switchcraft Inc. RAPC722X
1 J2 120-pin socket, 0.6 mm Hirose Electric FX8-120S-SV(21)
To Next Page
