UG-1134 EVAL-ADAU1467Z
Rev. A (Draft) | Page 52 of 55
Qty Reference Designator Description Manufacturer Part Number
1 J3 3-position session initiation protocol (SIP)
header, 3-jumper
Sullins PBC03SAAN or cut
PBC36SAAN
1 J5 14-way shroud polarized header, 2 × 7 3M N2514-6002RB
1 J7 TOSLINK, 16 Mpbs, optical transmitter Everlight Americas PLT133/T10W
1 J8 16-way unshrouded, 2 × 8 3M PBC08DAAN, or cut
PBC36DAAN
1 J9 14-way unshrouded header, 2 × 7 3M PBC07DAAN, or cut
PBC36DAAN
2 L1, L2 47 µH inductor Taiyo Yuden CBMF1608T470K
1 L3 Inductor surface mount technology (SMT),
9.0 µH
Wurth Electronics
Inc.
744052009
1 Q1 PNP transistor, D-PAK, STMicroelectronics STD2805T4
12 R1, R5, R7, R8, R10, R16 to
R19, R22, R23, R148
Chip resistors ,1%, 63 mW, thick film 0402,
33.2 Ω
Stackpole RMCF0402FT33R2
2 R105, R106 Chip resistors, 5%, 125 mW, thick film, 0805,
0.00 Ω
Panasonic EC ERJ-6GEY0R00V
1 R11 Chip resistor, 1%, 100 mW, thick film ,0402,
Panasonic ECG ERJ-2RKF4321X
R12, R14, R75, R150, R151
Resistor network isolated, 4 resistors, 33R0
1 R13 Chip resistor, 1%, 63 mW, thick film, 0402,
47.0 kΩ
Yageo RC0402FR-0747K0L
4 R15, R31, R32, R107 Chip resistors, 1%, 63 mW, thick film, 0402,
1.0 kΩ
Yageo RC0402FR-071KL
7 R2, R3, R6, R29, R30, R41, R42 Not applicable Not applicable Not applicable
1 R20 Chip resistor, 1%, 167 mW, thick film, 0402,
0.47 Ω
Panasonic ERJ ERJ-2BQFR47X
5 R21, R28, R34, R70, R72 Chip resistors, 1%, 63 mW, thick film, 0402,
2.43 kΩ
Vishay/Dale CRCW04022K43FKED
1 R24 Chip resistor, 1%, 63 mW, thick film, 0402,
562 Ω
Stackpole RMCF0402FT562R
2 R25, R26 10.0 kΩ potentiometers, 9 mm, vertical,
10.0 kΩ linear taper
Panasonic EC EVU-F2MFL3B14
18 R27, R40, R54 to R56, R63,
R66, R91, R95, R99, R121,
R124, R128, R135, R137 to
R139, R143
Chip resistors, 1%, 63 mW, thick film, 0402,
49.9 Ω
Yageo RC0402FR-0749R9L
14 R33, R49, R51 to R53, R62,
R94, R102, R127, R136,
R140, R141, R142, R146
Chip resistors, 1%, 100 mW, thick film, 0402,
100 k
Panasonic ECG ERJ-2RKF1003X
1 R35 Chip resistor, 5%, 100 mW, thick film, 0402,
0.00 Ω
Panasonic ECG ERJ-2GE0R00X
32 R36, R37, R57 to R59, R64,
R67, R83, R84, R86 to R89,
R92, R93, R96, R98, R100,
R101, R109, R110, R113,
R114, R118 to R120, R122,
R125, R126, R129, R134,
R144, R145
Chip resistors, 1%, 63 mW, thick film, 0402,
4.99 kΩ
Stackpole RMCF0402FT4K99
8 R38, R39, R43, R45, R46,
R48, R50, R79
Chip resistors, 1%, 63 mW, thick film, 0402,
475 Ω
Stackpole RMCF0402FT475R
2 R4, R104 Chip resistors, 5%, 250 mW, thick film, 1206,
0.00 Ω
Panasonic EC ERJ-8GEY0R00V
R44, R47, R60, R61, R68, R73,
R76 to R78, R80 to R82, R85,
R88, R90, R108, R111, R112,
R115 to R117, R131, R132
Chip resistors, 1%, 100 mW, thick film, 0402,
10.0 kΩ
5 R9, R65, R97, R103, R130 Chip resistors, 1%, 63 mW, thick film, 0402,
100 Ω
Yageo RC0402FR-07100RL
To Next Page
