EVAL-ADAU1467Z UG-1134
Rev. A (Draft) | Page 53 of 55
Qty Reference Designator Description Manufacturer Part Number
1 S1 Tactile switch, 6 mm, gull wing, SPST-NO Tyco/Alcoswitch FSM6JSMA
1 S2 Double-pole, double-throw (DPDT) slide
switch, DPDT slide
E-Switch EG2207
1 S3 4 section SPST SMD switch raised act, 4× SPST CTS Corp 219-4MST
4 S5 to S8 Single-pole, double-throw (SPDT) slide
switches, SMD J hook, SPDT
Copal Electronics CAS-120TA
1 U1 IC clock buffer 1:9, 16-lead SOIC On Semiconductor PCS2I2309NZG16SR
SPI EEPROM, 128k × 8 (1 Mbit), 20 MHz
1 U17 High accuracy, low dropout, 3.3 V dc voltage
regulator
Analog Devices ADP3338AKCZ-3.3-R7
1 U2 300 MHz, SigmaDSP Analog Devices ADAU1467WBCPZ
1 U3 4 ADC/8 DAC with phase-locked loop (PLL),
192 kHz, 24-bit codec
Analog Devices AD1937WBSTZ
JFET input, single op amp, SOT-23,
1 U5 Microprocessor voltage supervisor, logic
low reset output
Analog Devices ADM811MARTZ-REEL7
1 U6 Microprocessor voltage supervisor, logic
low reset output
Analog Devices ADM811TARTZ-REEL7
IC inverter HEX 14-SOIC, 74ACT04SC
8 U8, U9, U11 to U16 Dual low power, low noise, and distortion
rail-to-rail output amplifiers
Analog Devices ADA4841-2YRMZ
1 Y1 Crystal, 12.288 MHz, 18 pF Abracon Corp ABM3B-12.288MHZ-10-1-U-T
48 C1, C3 to C7, C9, C11, C12,
C14, C17, C20, C22, C24,
C26 to C29, C40, C41, C43,
C45, C47, C50, C52, C55 to
C60, C64, C65, C72, C75 to
C77, C90, C92, C97, C98,
C112, C114, C119, C122,
C128, C133, C134
Multilayer ceramic capacitors, 16 V, X7R
(0402), 0.10 µF
Murata ENA GRM155R71C104KA88D
2 C100, C101 Aluminum electrolytic capacitors, 105°C,
SMD_B, 10 µF
Panasonic EC EEE-FC1C100R
2 C129, C130 Multilayer ceramic capacitors, 16 V, X7R
(0603), 1.0 µF
Murata ENA GRM188R71C105KA12D
26 C13, C18, C46, C51, C61 to
C63, C71, C74, C86, C88, C91,
C93, C95, C99, C102, C113,
C115, C117, C121, C124,
C135 to C139
Multilayer ceramic capacitors, 10 V, X7R
(0805 ), 10 µF
Murata ENA GRM21BR71A106KE51L
2 C131, C132 Aluminum electrolytic capacitors, 105°C,
100 µF
Panasonic EC EEE-FC1C101P
4 C15, C16, C42, C44 Multilayer ceramic, capacitors 25 V, X7R
(0402), 10 nF
Murata GRM155R71E103JA01J
2 C19, C49 Multilayer ceramic capacitors, 25 V, NP0
(0402), 5.6 nF
Murata GRM155R71E562KA01D
Tantalum capacitor, 105°C, 47 µF
1 C21 Multilayer ceramic, 50 V, NP0 (0402), 150 pF Murata ENA GRM1555C1H151JA01D
1 C25 Ceramic capacitor, 6.3 V, X7R 1210, 47.0 µF Murata GCM32ER70J476KE19L
8 C30, C33, C36, C53, C89,
C96, C118, C127
Multilayer ceramic capacitors, 50 V, NP0
(0402), 100 pF
Murata ENA GRM1555C1H101JA01D
8 C31, C32, C34, C35, C37 to
C39, C54
Multilayer ceramic capacitors, 50 V, NP0
(0402), 1.0 nF
Murata ENA GRM1555C1H102JA01D
1 C48 Multilayer ceramic capacitor, 50 V, NP0
(0402), 390 pF
Murata ENA GRM1555C1H391JA01D
16 C66 to C68, C73, C79 to C82,
C103 to C105, C109 to
C111, C120, C125
Multilayer ceramic capacitors, 50 V, NP0
(0402), 33 pF
Murata ENA GRM1555C1H330JA01D
To Next Page
