Analog Devices SigmaDSP ADAU1463 User Manual

UG-1134 EVAL-ADAU1467Z
Rev. A (Draft) | Page 54 of 55
Qty Reference Designator Description Manufacturer Part Number
8 C69, C70, C78, C85, C106 to
C108, C123
Multilayer ceramic capacitors, 50 V, NP0
(0402), 82 pF
Murata ENA GRM1555C1H820JA01D
2 C8, C10 Multilayer ceramic capacitors, 50 V, NP0
(0402), 22 pF
Murata ENC GRM1555C1H220JA01D
2 C83, C84 Aluminum electrolytic capacitors, 105°C,
SMD_D, 47 µF
Panasonic EC EEE-FC1C470P
4 C87, C94, C116, C126 Multilayer ceramic capacitors, 50 V, NP0
(0402), 330 pF
Murata ENA GRM1555C1H331JA01D
9 D1 to D9 LED, 3 millicandela, 571 nm, 0603, green Lite-On LTST-C191KGKT
9 GND1 to GND9 Test point, black Keystone
Electronics
5001
2 J1, J6 10-way shroud polarized headers, 2 × 5 3M N2510-6002RB
1 J10 TOSLINK ,16 Mpbs, optical receiver Everlight Americas PLR135/T10
1 J11 120-pin header, 0.6 mm Hirose Electric FX8-120P-SV1(91)
6 J12 to J18 Stereo mini jacks, SMT CUI Inc. SJ-3523-SMT
9 GND1 to GND9 Test points, black Keystone
Electronics
5001
67 3V3_A, 5V0_UNREG,
ADCL1N, ADCL2N ADCL1P,
ADCL2P, ADCR1N, ADCR2N,
ADCR1P, ADCR2P,
AUXADC2 to AUXADC7,
BCLK_IN2, BCLK_OUT0,
CM_BIAS, DACL1N to
DACL4N, DACL1P to
DACL4P, DACR1N to
DACR4N, DACR1P to
DACR4P, DVDD, IN1L, IN1R,
IN2L, IN2R, LRCLK_IN2,
LRCLK_OUT0, MCLKOUT,
MISO_M, MOSI_M, OUT1L
to OUT4L, OUT1R to
OUT4R, SCLK_M, SDATAIO4
to SDATAIO7, SDATA_IN2,
SDATA_OUT0, SDP_RESET,
SPDIF_IN, SPDIF_OUT,
SS_M, THD_M, THD_P,
VDRIVE
Test points, white Keystone
Electronics
5002
RELATED LINKS
Resource Description
ADAU1467 ADAU1463/ADAU1467 data sheet
SigmaStudio SigmaStudio Software
DRAFT
