Analog way SmartMatriX2 User Manual

59
Even the logo and frame buons can access to their own sengs, but a logo/frame# has to be aected too.
The Program output can displayed simultaneously up to 5 layers stacked from boom to top as follows:
 one stored frame selected from 8 available,
 one source selected from 10 inputs available,
 one source selected from 10 inputs available,
 one stored logo selected from 8 available,
 one of the 8 frames available.

When transioning live layers, depending on how many scalers are in use, the SmartMatriX² TAKE funcon
will act in one of 3 dierent ways when transioning the next preset (Preview) to the current preset (Program):
• TAKE
- There are enough scalers for making a transion
- All inputs are locked on to scalers
- There are no contraints for closing before the TAKE
- All opening and closing transions can be performed simultaneously.
• TAKE
- There are enough scalers for making a transion
- All inputs are locked on to scalers before the TAKE
- There are no constraints for closing during the TAKE
- All the necessary closing transions are performed to free occupied scalers and then the SmartMatriX²
performs all openings (for example, when a frame or a logo needs to be changed, except with Cut eect).
• TAKE
- There are not enough scalers for making a transion
- All inputs are not locked on to scalers
- All the necessary closing transions are performed to free occupied scalers. The SmartMatriX² locks on to
new sources and performs all openings.
8.2.8 Layer adjustment menu
• To have access to the layer adjustment menu, a source has to be aected to your layer:

• Once a source is aached to layer, you can have access to the layer adjustment menu:

Press TAKE
• To adjust layers, there is a shortcut on a front panel too:


All the transions (Cut, Fade or Transions) are available in the nave Matrix mode. You will be able to per-
form powerful transion eects seamlessly. It can depend on your conguraon.
The SmartMatriX² has 4 scalers, to understand how your eect will be performed, you need to know how
many scalers are used on your outputs. Don’t forget that you always need one free scaler to perform seamless
transions.
Example:
8.2.6 Working with layers funcons
