58
8.2.5 Working with layers


Press TAKE to view the result on both screens
Don’t forget to press the correct Matrix # buon before pressing the Layer selecon buon, in order to be
sure doing the manipulaon on the correct output.

Once a source is assigned to a layer, you will have access to some layer sengs in the Layer menu or direct-
ly by pressing the layer buon.
The sengs available depend on the layer selected:
 select the copy and adjustment
 set up layer size and posion,
set up layer zoom size and posion,
 adjust a specic size (Fullscreen, 1/2, 1/3, ...),
 adjust the layer transparency,
 choose the border and adjust its properes,
 enable/disable the selected transions
 adjust the Open/Close eect type and duraon,
 enable/disable smooth move,
 ip the data of the layer,
 get the selected layer status.
All changes have to be validated by pressing the ENTER buon in order to be saved
Press TAKE

  PIP#2
Posion YES YES
Size YES YES
Zoom YES YES
Transparency YES YES
Border YES YES
Opening eects YES YES
Closing eects YES YES
Smooth Move YES YES
H Flip / V Flip YES YES
2 layers  
