57
 set up the type of color space of your digital output,
 DVI output content as HDMI. Audio is included,
enable or not the HDCP detecon on the output,
 display the centering test paern,
 choose to display one of the available test paern.
All changes have to be validated by pressing the ENTER buon in order to be saved
NOTE: The output status can provide you all informaon about the output in real me. This feature is
parcularly needed when HDCP is used with long cable to be sure that the communicaon is well
handled.

The Video Out allows you the same sengs as other outputs with some addional specic opons:
 set up the sharpness on the video out image,
 apply a icker lter on your video output to eliminate ickering,
enable or not the automac video zoom overscan,
- ADJUST: adjust your video output in term of H/V posion and size.
In nave Matrix mode, the menu allows you to choose recording Output #1 or Out-
put #2.
In Matrix mode, the SDI output embeds audio from Output #1 and Output #2.

To work with nave Matrix mode, you have to use the Matrix # buons rst.
For instance, if you want to put the frame #1 on the Output #1 and the live source #3 on the output #2:
8.2.4 Output selecon sengs
 
Output #1
Output #1 & #2 side by side
OUT #1
OUT #1
OUT #1
Output #2
Output #1 & #2 Top and Boom
OUT #2
OUT #2
OUT #2




