56
8.2.2 Input selecon sengs
You can nd several sengs for each input (some sengs are specic to some signal type):
 display the input status,
 launch an automac setup on the inputs,
- FREEZE: freeze the input,
 choose the acve plug of the input,
 to set up your input type (Computer, Video etc..),
launch an autoset on this plug,
 enable/disable the input#,
enable this opon when you source is from the same refresh rate than the reference rate,
 enable/disable the HDCP automac detecon,
 to change the load of the sync signal,
 choose manually the combo lter for interlaced source,
 for analog source, choose to force a analog format,
 select the input audio source according to the input video source,
 set up your EDID for the selected plug,
 to summarize the input status.
Concerning the HDMI®inputs, a specic feature allows enable/disable the HDCP receiver for the input chosen.
It can be very useful especially using a Mac: 
NOTE: The input status is available at any me in the status input menu and can give you informaon about
format rate and HDCP status.

Once your inputs all have been congured, the output sengs of the SmartMatriX² must be set according
to the machines plugged on your SmartMatriX² Program and Preview outputs (video projector, Preview
monitor...).
NOTE: If you want to use HDCP content from your sources, be sure to aach HDCP compliant screens or
projectors. If HDCP sources are used with non-HDCP compliant screens, the output image could be
disabled.

To set up the output, go in the Program Output #1 or Program Output #2 menu and choose rst the adapted
format/resoluon, and then the appropriate rate for your screens by using the knob buon and the ENTER
buon.

Please note that a pair format/rate is only applied when the rate is validated.
Use the nave resoluon of your screens/projectors in order to obtain the best image quality. In the Program
Output #2 menu, you can also match the output conguraon the Program Output #1 to the Program Output
#2 by checking the case Sync w/Out 1. It allows you to set up your outputs via the output 1 menu.

Some other sengs are available too:
display the status of the selected output,
 choose the output format,
 choose the output rate,
 use this feature to set up the output gamma,
set up the type of synchronizaon of your analog output,
