Page 49
MR8018
MR8518
Frequency range
UL
DL
806 MHz to 824 MHz
851 MHz to 869 MHz
824 MHz to 849 MHz
869 MHz to 894 MHz
RF output power
4)
UL / DL
+22 dBm @ 1 carrier
+19 dBm @ 2 carriers
OICP3 UL / DL +41 dBm
P-1dBc UL / DL +28 dBm
Noise figure UL / DL 6.0 dB @ maximum gain
Input and output impedance 50 Ohms
Spurious emission <-13 dBm
Gain 70 dB
Gain adjust range 30 dB in steps of 1
Bandwidth options
variable 1 MHz to 25 MHz
in steps of 10 kHz
Flatness ±3 dB
Delay 5 µs
Mains power 100 Vac to 240 Vac
Power supply
Local power 6 Vdc
Power consumption 20 watts
Connectors SMA Female
Antenna port
Return loss 10 dB
Antenna gain 2.0 dBi Indoor antenna
(optional)
Radiation Omni
System Supervision and Control
Alarms Temperature, Current, ALC
Options Remote control and heartbeat via SMS
All figures are typical values.
4)
) Note: The manufacturer's rated output power of this equipment is for single carrier
operation. For situations when multiple carrier signals are present, the rating would
have to be reduced by 3.5 dB, especially where the output signal is re-radiated and
can cause interference to adjacent band users. This power reduction is to be made
by means of input power or gain reduction and not by an attenuator at the output of
the device.
All data is subject to change without notice.
