Page #41 background imageLoading...
Page #41 background image
Copyright by Servizio Clienti ANGELO PO Spa
41
3.7. FX fuses description:
Power board:
F3- pcb relay and halogen light transformer fuse (250mAT)
F4- steam production water solenoid, quenching water solenoid, motorised valve (3,15AT)
F5- General fuse for oven aux circuits, heating elements contactors, first chamber inverter
and/or combustion control contactors, washing water solenoid (6,3AF)
Power Board Expansion module (level 3 only):
F1- General fuse for low power contactors, detergent / sanitiser pumps, external fats drain
valve, second chamber aux circuits ( inverter contactor and/or combustion control
contactor) (3.15 AT)
230V/12V PCBs power supply Transformer
F1- On board 230V Primary fuse (630mAT)
F4, F5- Outputs (on wiring) fuses (3,15 AT)
Wiring (only electric models):
F1, F2- fuses on phase L1 and L2 (10AT Class CC 600 Volts)
F6- “Neutral” ( L2 Phase ) 230V pcb I/O fuse: on wiring, close to F4, F5 (3,15 AT)
On 480 Volts model only:
F3- fuse on phase L3 (10AT Class CC 600 Volts)
F7- fuse (2A 500 Volts)
ONLY gas models:
T3 120V/230V Aux Transformer: on board primary fuse:
- 2.5AT on 160VA Transformer (for models FX61G, FX101G and FX82G gas Ovens )
- 6,3 A T on 330VA Transformer (other models gas Ovens )
Blower control pcb:
F1- board general fuse (4A F), blower and combustion control board supply circuits.
Combustion control pcb:
F1----- board general fuse (6,3A T), protects also gas valve supply circuit.
NOTE: T=slow, F=fast.
