• Do not allow the cord to hang over the edge of the work surface or to come into contact
with stoves or other hot surfaces.
• If the cord or plugs are worn or damaged, do not use.
• Unplug from the power socket by grasping the plug body - Do Not pull on the cord.
Read and Save These Instructions
2 Components
1 Front Grille
2 Locking Screw
3 Fan Grille Lock / Band
4 Fan Blade Spinner Nut
5 Fan Blade
6 Rear Grille Nut
7 Rear Grille
8 Motor Head Assembly
9 Control Body
10 Head to Post Locking Screw
11 Inner chrome tube
12 Height Adjustment Locking Screw
13 Stand Post
14 Base Cover
15 Base W eight
16 Screw and W asher
17 Remote Control
1
2
3
4
5
6
7
8
9
11
10
12
13
14
16
15
17
