Command Directory 3-4 Commands
MG369xC GPIB PM PN: 10370-10374 Rev. F 3-115
SR1
Description: Enable synchronization of the AM and FM/PM randomizers.
Serial command: 0x04ba
Functional
Category: MODULATION
Example: SR1
Related
Commands: SR0, WFS
Front Panel Key: NA
SSN(m)
Description: Saves the current instrument setup to internal setup memory location M specified as
(1 to 9).
Functional
Category: STORED SETUP
Value: m: memory locations 1 to 9
Related
Commands: RSN(m)
Front Panel Key: System | Setups | Save (enter setup number)
SSP
Description: Selects linear step sweep.
Same as LIS. SSP, by itself, does not provide a swept-frequency output. It only
determines that the swept-frequency output will be a linear step sweep. However, if a
frequency sweep is being output by the instrument when SSP is received, the sweep will
become a linear step sweep.
Functional
Category: SWEEP
Example: SDT 3 MS; SNS 100 SPS; SSP; SF1; AUT
Initiates a continuous linear step frequency sweep between F1 and F2. The sweep
consists of 100 steps with a dwell-time-per-step of 3 ms.
Output Command: OSD returns the dwell time of the step sweep (in ms) to the controller.
OSS returns the number of steps of the step sweep to the controller.
OST returns the sweep time value (in ms) to the controller.
Related
Commands: LGS, LIS, MAN, SWP
Front Panel Key: Frequency | Step Sweep | More > | Log/Linear to Linear
Note
The SR1 command should be sent before the WFS and waveform data are sent to the signal
generator. The commands will not function properly if not sent in the correct order.
