2-5 CW Frequency Commands
Table 2-5 lists the CW frequency command mnemonic codes. These commands call up each of the 20 preset
(or previously set) CW frequencies. Each command causes its associated CW frequency to be output and opens
that frequency’s parameter for data entry.
The command, SQF, accesses the preset frequencies in sequential order—that is, F0 to F9 and M0 to M9.
Programming Note:
Signal generator response to a SQF command depends on the state the instrument is in at the time the
command is received. For example, if the MG369xC is in a CW mode of operation with the current output
frequency open for entry, the SQF command (1) causes the output to change to the next sequential frequency
and (2) opens that frequency’s parameter for data entry. However, if the instrument is in any other mode of
operation, the SQF command causes it to switch to the last CW frequency that was output and opens that
parameter for data entry.
Table 2-5. CW Frequency Commands
Mnemonic Description
ACW Activates the currently scanned frequency as CW.
CF0 Set CW mode at F0, Opens F0 parameter.
CF1 Set CW mode at F1, Opens F1 parameter.
CF2 Set CW mode at F2, Opens F2 parameter.
CF3 Set CW mode at F3, Opens F3 parameter.
CF4 Set CW mode at F4, Opens F4 parameter.
CF5 Set CW mode at F5, Opens F5 parameter.
CF6 Set CW mode at F6, Opens F6 parameter.
CF7 Set CW mode at F7, Opens F7 parameter.
CF8 Set CW mode at F8, Opens F8 parameter.
CF9 Set CW mode at F9, Opens F9 parameter.
CM0 Set CW mode at M0, Opens M0 parameter.
CM1 Set CW mode at M1, Opens M1 parameter.
CM2 Set CW mode at M2, Opens M2 parameter.
CM3 Set CW mode at M3, Opens M3 parameter.
CM4 Set CW mode at M4, Opens M4 parameter.
CM5 Set CW mode at M5, Opens M5 parameter.
CM6 Set CW mode at M6, Opens M6 parameter.
CM7 Set CW mode at M7, Opens M7 parameter.
CM8 Set CW mode at M8, Opens M8 parameter.
CM9 Set CW mode at M9, Opens M9 parameter.
SQD Scan down to the next lower preset CW frequency.
SQF Scan to the next higher preset CW frequency.
SQU Scan up to the next higher preset CW frequency.
