General GPIB Information 1-9 Ethernet LAN TCP/IP Requirements and Setup
MG369xC GPIB PM PN: 10370-10374 Rev. F 1-19
7. Click Reboot button for the changes to take effect or power cycle the unit later to activate the changes.
8. After reboot is complete, find the IP address that was assigned by the network to the MG369xC
Ethernet/GPIB Controller.
9. To validate your TCP/IP connection, at the PC browser, enter the IP address of the MG369xC.
The Model MG369xC Welcome Page should again appear, this time with the new IP address in the
Current Setup summary.
Testing the TCP/IP Connection Over LAN
1. Connect the MG369xC Ethernet port to the LAN.
2. Using a PC that is also connected to the LAN, enter the LAN IP address into an open web browser. The
Model MG369xC Welcome Page should appear, with the new IP address in the Current Setup summary.
Note When rebooting, it can take three to five minutes for the changes to take effect.
Figure 1-10. Ethernet Configuration Confirmation Page
Note
The MG369xC MAC address can be used to find its IP address on the Network by sending the com-
mand “arp -a” via a DOS command prompt. The MAC address can be found on the back panel of the
instrument and is also shown on the Welcome web page for the instrument.
Alternatively, the user can query “*IDN?” on the available network instruments to locate the IP
address of the MG369xC.
