A-4 Functional Listings
MG369xC GPIB PM PN: 10370-10374 Rev. F A-15
A-4 Functional Listings
Table A-2. Configuration GPIB Command List
Command Code Function Page
BPN Selects -3.3V for retrace and bandswitch blanking outputs. 3-14
BPP Selects +3.3V for retrace and bandswitch blanking outputs. 3-15
EBW0 Selects the external reference loop bandwidth of 10 Hz. 3-30
EBW1 Selects the external reference loop bandwidth of 30 Hz. 3-30
EBW2 Selects the external reference loop bandwidth of 100 Hz. 3-31
EBW3 Selects the external reference loop bandwidth of 300 Hz. 3-31
FRS Opens the frequency scaling reference multiplier parameter. 3-44
RC0 Selects RF to be off during frequency switching in CW, step sweep,
and list sweep modes.
3-97
RC1 Selects RF to be on during frequency switching in CW, step sweep,
and list sweep modes.
3-97
RO0 Selects RF to be on at reset. 3-98
RO1 Selects RF to be off at reset. 3-98
RT0 Selects RF to be off during retrace. 3-99
RT1 Selects RF to be on during retrace. 3-99
TR0 Sets 0dB of attenuation when RF is switched off. 3-118
TR1 Sets 40dB of attenuation when RF is switched off. 3-118
