Chapter 1
Frequency Span
S114B
S332B
0 Hz (zero span) 100 kHz to 1200 MHz
0 Hz (zero span) 100 kHz to 3000 MHz
Sweep Time 0.5 sec.
Resolution Bandwidth
(-3 dB width)
10 kHz, 30 kHz, 100 kHz, 1 MHz ,+/- 20%
Video Bandwidth
(Range –3 dB) 3 kHz, 10 kHz, 30 kHz and 300 kHz
SSB Phase Noise
@ (1 GHz) 30 kHz offset £ –74 dBc/Hz
Spurious Responses
Input Related £ –45 dBc
Spurious
Residual Responses £ –80 dBm
Note: 10 kHz resolution bandwidth, input terminated, no attenuation
Amplitude
Measurement Range –90 dBm to +20 dBm
Dynamic Range ³ 60 dB
Maximum Safe Input Level +20 dBm, maximum measurable safe input
+27 dBm, maximum damage
+27 dBm, peak pulse power
+50 Vdc
Displayed Average Noise
Level: £ –90 dBm (400 kHz span)
Display Range
Log Scale 2 to 15 dB/div. In 1 dB steps. Ten divisions dis-
played.
Frequency Response
RF Input VSWR 2.0:1
Resolution (Ref. Level) 1.0 dB
Total Level Accuracy ±2.0 dB
General
Internal Memory:
Trace Memory
Instrument config.
RS-232
200 maximum
10 setup locations
9 pin D-sub, three wire serial
Electromagnetic Compatibility Meets European community requirements for
CE marking
Power Supply:
External DC Input +12.5 to +15 Vdc, 1100 mA max.
Temperature:
Storage
Operation
–20° C to 75° C
0° C to 50° C
Weight: 1.82 kg (4.0 pounds)
Dimensions: 25.4 x 17.8 x 6.1 cm
(10x7x2.4inches)
* ±2 ppm/D°C from 25°C
** Fault location is accomplished by inverse Fourier Transformation of data taken with the Site Master. Resolution and
maximum range depend on the number of frequency data points, frequency sweep range and relative propagation veloc
-
ity of the cable being tested.
Table 1-2. Performance Specifications (2 of 2)
