Viewing and Printing a Read Status 4. Read Status Operation
IQ-636X Operations Manual P/N 52181:A 04/28/2005 43
How to View Read Status of Devices, Zones, and System Settings
Overview
Read Point options 0, 2, and 4 in the Read Status Screen let you display and view information for
devices and zones programmed into the control panel, as well as view system and annunciator settings.
This section provides instructions and sample displays so you can view Read Status.
Topics covered in this section:
How to Display the Total of Installed Devices
To view the total number of installed devices, enter the “Read Status” screen by
pressing the
ENTER key, then 2, then A. A screen similar to the following will
appear:
How to Display a Point or Zone for Read Status
From the “Read Status” screen, press 0, then press the
ENTER key to
display the “Read Point Entry” screen as shown below:
• To view a detector, press
DETECTOR , SLC number, detector SLC address, ENTER.
• To view a zone, press , zone number,
ENTER.
• To view a monitor or control/relay module, press
MODULE , SLC number, module SLC
address,
ENTER.
• To view a Panel Circuit or a NAC, press
OUTPUT , two-digit address, (for example 01 for
B01, 11 for Panel Circuit 1.1, etc.),
ENTER.
When you select a device or a zone, the control panel displays information for the device or zone, but
does not send this information to the serial ports or the History buffer.
To view Read Status for Refer to
Intelligent Detectors “How to View Read Status for a Detector” on page 44
Control/relay and Monitor
modules
“How to View Read Status for a Control/Relay or
Monitor Module” on page 45
NAC and Panel Circuits “How to View Read Status for a NAC or Panel Circuit”
on page 46
Software Zones (Z01-Z99) “How to View Read Status for a Software Zone (Z01-
Z99)” on page 47
Special Zones (F0-F9) “How to View Read Status for a Special Zone (F0-F9)”
on page 47
Releasing Zones (R0-R9) “How to View Read Status for a Releasing Zone
(R0-R9)” on page 47
System Functions “How to Read Status for System Functions” on page 48
Annunciator Selections “How to Read Status for Annunciator Selections” on
page 49
L1:159Dets, 159Mods L2:055Dets, 047Mods
Panel Outputs: 64 Bells: 04
ZONE=Z,AA,E DETECTOR=*,LDAAA,E
MODULE=#,LMAA,E OUTPUT CKT=8,AA,E
To Next Page
