IQ-636X Operations Manual P/N 52181:A 04/28/2005 9
About This Manual
Cautions and Warnings
This manual contains cautions and warnings to alert the reader as follows:
Typographic Conventions
This manual uses the following typographic conventions as listed in below:
Supplemental Information
The table below provides a list of documents referenced in this manual, as well as documents for
selected other compatible devices. The document series chart (DOC-ANS) provides the current
document revision. A copy of this document is included in every shipment.
!
CAUTION: Information about procedures that could cause programming errors, runtime errors,
or equipment damage.
!
WARNING: Indicates information about procedures that could cause irreversible damage to the
control panel, irreversible loss of programming data or personal injury.
When you see Specifies Example
text in small caps the text as it appears in the LCD
display or on the control panel
MARCH TIME is a selection that appears in the
LCD display; or Press the ENTER key
text in quotes a reference to a section or a
LCD menu screen
“Read Status”; specifies the Read Status
section or menu screen
bold text In body text, a number or
character that you enter
Press 1; means to press the number “1” on the
keypad
italic text a specific document IQ-636X Installation Manual
a graphic of the key In a graphic, a key as it appears
on the control panel
Press means to press the Escape key
Table 1 Typographic Conventions in this Manual
Compatible Conventional Devices (Non-addressable)
Document Number
(Ansul part no. if
applicable)
Device Compatibility Document 50054
Fire Alarm Control Panel (FACP) and Main Power Supply Installation
Document Number
(Ansul part no. if
applicable)
IQ-636X Installation, Operations, and Programming Manuals 52180 (432779),
52181 (432778),
52182 (432777)
Ansul SLC Wiring Manual 52184
Note: For individual SLC Devices, refer to the SLC Wiring Manual
Off-line Programming Utility
Document Number
(Ansul part no. if
applicable)
VeriFire™ Tools CD help file ANSUL-TCD
Table 2 Supplemental Documentation (Sheet 1 of 2)
