Antelope ZEN QUADRO - Dual Usb-Otg Use Cases; Two Computers

Antelope Audio Zen Quadro Synergy Core User Manual
Page 27
- To use the Secondary USB 2 port with a mobile device ONLY requires your mobile
device to deliver enough power. In case the Zen Quadro cannot boot up, you can plug
an additional power supply to the primary USB 1 port.
- To use with an Apple device with Lightning port, you need to use an Apple Camera kit
adapter which allows the mobile device to work as a Host and the Zen Quadro SC as a
device.
A standard Lightning to USB-C cable is not compatible.
- For the Reverse charging functionality to work, a 5V with at least 1.5A should be
supplied to the primary USB 1 port. We recommend using USB3.1/3.2 or Thunderbolt
3/4 ports for optimal performance.
DUAL USB-OTG USE CASES
The two USB-C ports on the Zen Quadro Synergy Core unlock a variety of connectivity
combinations to experiment with. The main options are the following:
Two computers
Connect two computers simultaneously to play and mix audio signals together, using the
same outputs. Connect your headphones, speakers and DJ mixer to have full control over the
