Page 37
the stereo field to the other. If panning audio
left and right causes a noticeable difference
in perceived volume level, adjust Panning
Law compensation to calibrate the
interface's outputs to your listening
equipment.
DC-COUPLED INPUTS/OUTPUTS
Turn on or off the DC-coupling of the
analog inputs and outputs (monitor outs/line
outs)
Click to mute or un-mute Oscillator 1.
Click to choose Oscillator 1 frequency
(440Hz or 1kHz). Oscillator 1 generates a
test signal which is fed to the monitor
outputs for troubleshooting and calibration.
Click to choose the output level for
Oscillator 1 and Oscillator 2 (-18dBFS -
0dBFS).
Click to choose Oscillator 2 frequency
(440Hz or 1kHz). Oscillator 2 generates a
test signal which is fed to the monitor
outputs for troubleshooting and calibration.
Click to mute or un-mute Oscillator 2.
For Windows users - click to launch the Zen
Quadro Synergy Core USB ASIO Control
Panel. The 'Buffer Settings' tab lets you
