AnyTone Ares User Manual

9
SLIDE SWTICH
No. Function Position Description
1 NB/ANL
NB/ANL
ANL
OFF
Trun on NB and ANL function
NB/ANL
ANL
OFF
Turn on ANL fucntion
NB/ANL
ANL
OFF
Turn off NB/ANL fucntion
2 RF Power
HI
LO
Set on high RF power AM: 10W FM: 10W
HI
LO
Set on super RF power AM: 10W FM: 30W
HI
LO
Set on low RF power AM: 4W FM: 4W
3
MON
+ 10K
MON
OFF
+1OK
Turn on MON, 32 levels available by programming
MON
OFF
+1OK
No function
MON
OFF
+1OK
Turn on +10KHz function
4 DIM
H
M
L
LED brightness is high level
H
M
L
LED brightness is middle level
H
M
L
LED brightness is low level
5 BAND
H
L
Choose higher frequency band group
H
L
Turn on Weather channel function(Optional)
H
L
Choose lower frequency band group

AnyTone Ares Specifications

General

Bluetooth	No
GPS	No
Operating Modes	FM
Display	LCD
Waterproof	No
