APC SMART-UPS 750 User Manual

5
2: OPERATION
Front Display Panel
INDICATOR DESCRIPTION
Online
The UPS is supplying utility power to the connected equipment.
AVR Trim The UPS is compensating for a high utility voltage.
AVR Boost
The UPS is compensating for a low utility voltage.
On Battery
The UPS is supplying battery power to the connected equipment.
Overload
The connected loads are drawing more than the UPS power rating.
Replace Battery/
Battery Disconnected
The battery is disconnected or must be replaced.
F
EATURE
F
UNCTION
Power On
Press this button to turn on the UPS. (Read on for additional capabilities.)
Power Off Press this button to turn off the UPS.

APC SMART-UPS 750 Specifications

General

Output Power Capacity	500 Watts / 750 VA
Nominal Output Voltage	120V
Nominal Input Voltage	120V
Waveform Type	Sine wave
Output Connections	(6) NEMA 5-15R
Control panel	LED status display with On Line: On Battery: Replace Battery and Overload indicators
Form Factor	Tower
Battery Type	Lead-acid battery
Transfer Time	6 ms typical
Input Frequency	50/60 Hz
Output Frequency	50/60 Hz
Typical Recharge Time	3 hours
Interface Port(s)	USB
Output Voltage	120V
Communication Ports	USB
