Smart-UPS 750-3000 VA 120/208/230 Vac Rack-mount2
Rear panels
SmartSlot for optional NMC accessory card
UPS input
Circuit breaker/Overload protection
Controlled outlet group
Chassis ground connection screw (TVSS GND)
Outlets
EPO connector
USB port
RJ45 connector - serial UPS monitoring port
750/1000/1500 VA 120 V 3000 VA 120 V
750/1000/1500 VA 230 V 3000 VA 208 V
2200 VA 120 V 3000 VA 230 V
su0644a
su0624a
su0645a
su0625a
su0623a
su0626a

Other manuals for APC SMART-UPS 750

Preview: User Manual
User Manual18 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the APC SMART-UPS 750 and is the answer not in the manual?

APC SMART-UPS 750 Specifications

General IconGeneral
Output Power Capacity500 Watts / 750 VA
Nominal Output Voltage120V
Nominal Input Voltage120V
Waveform TypeSine wave
Output Connections(6) NEMA 5-15R
Control panelLED status display with On Line: On Battery: Replace Battery and Overload indicators
Form FactorTower
Battery TypeLead-acid battery
Transfer Time6 ms typical
Input Frequency50/60 Hz
Output Frequency50/60 Hz
Typical Recharge Time3 hours
Interface Port(s)USB
Output Voltage120V
Communication PortsUSB
