APC SMART-UPS 750 User Manual

3Smart-UPS 750-3000 VA 120/208/230 Vac Rack-mount
Specifications
Operating Conditions
This unit is intended for indoor use only. Select a location sturdy enough to support the weight of the
UPS.
Do not operate the unit where there is excessive dust, or the temperature or humidity are outside the
specified limits.
Allow adequate space for proper ventilation.
Environmental Specifications
Environmental factors impact battery life. High temperatures, poor utility power, and frequent, short
duration discharges will shorten battery life.
For additional specifications, see the APC Web site at www.apc.com.
Installation
UPS
For UPS installation information, see the Smart-UPS Quick-Start Guide that is included with
the UPS. The guide is also available on the enclosed CD and the APC Web site at
www.apc.com.
Network Management Card
For installation information, see the user manual provided with the Network Management
Card (NMC). The user manual is also available on the APC Web site at www.apc.com.
Temperature
Operating 0° to 40° C (32° to 104° F)
Storage -15° to 45° C (5° to 113° F)
charge UPS battery every six months
Maximum
Elevation
Operating 3,000 m (10,000 ft)
Storage 15,000 m (50,000 ft)
Humidity
0% to 95% relative humidity, non-condensing

APC SMART-UPS 750 Specifications

General

Output Power Capacity	500 Watts / 750 VA
Nominal Output Voltage	120V
Nominal Input Voltage	120V
Waveform Type	Sine wave
Output Connections	(6) NEMA 5-15R
Control panel	LED status display with On Line: On Battery: Replace Battery and Overload indicators
Form Factor	Tower
Battery Type	Lead-acid battery
Transfer Time	6 ms typical
Input Frequency	50/60 Hz
Output Frequency	50/60 Hz
Typical Recharge Time	3 hours
Interface Port(s)	USB
Output Voltage	120V
Communication Ports	USB
