9Smart-UPS SRC 5000/6000/8000/10000 VA
Configuration
Using the display interface
Use the UP and DOWN keys to scroll through the main menu options. Press ENTER to view the
sub-menus under each main menu option. Press ESCAPE to exit a sub-menu and return to a main menu.
Standard menus
The Standard menus are the most commonly used menus for UPS configuration.
Advanced menus
The Advanced menus provide additional options for the UPS and are available only if the display
interface is configured to use the Advanced menus.
Menu General Functions
Status
View basic information about the UPS:
• Operating mode
• Information about the load
• Number of battery packs and the total number of Amp hours
• Battery voltage and capacity
• Estimated runtime
• Input and output voltage and frequency
• Information about the last transfer to battery power
• Self-test results
Configuration
Configure the settings for the UPS:
• Audible alarms
• Reset to Factory Defaults
• Select Standard or Advanced menus
Test & Diags
Use the Test & Diags menu to have the UPS perform a self-test.
About
Display information about this unit:
• Unit model number
• Serial number
• Battery installation date
• Suggested battery replacement date
Menu General Functions
Status
View detailed information about the UPS:
• Energy meter
• Load current
Configuration
Configure advanced settings for the UPS:
• Select Standard or Advanced menus
• Select the number of battery packs and the total number of Amp hours
• High and low transfer points
• Language
• Output voltage and frequency
• Low battery warning
• Minimum return capacity
• Return delay
• Shutdown delay
•Auto self-test
• Redundancy power alarm
Test & Diags
Perform a UPS alarm test or a runtime calibration test.
Log
View the event log for information about any changes to the UPS and any faults.
About
View information about the unit:
• Manufacture date
•Firmware version
