Smart-UPS SRC 5000/6000/8000/10000 VA10
UPS Settings
Configure the settings using the display interface or terminal mode.
Function Factory Default Options Description
Language English English, French,
German, Spanish,
Italian and Portuguese
Set the language used on the LCD manual.
Menu type Normal Normal, Advanced Select Advanced mode for extra information.
Output voltage UXI models:
230 VAC
XLICH/
UXICH models:
220 VAC
220, 230, 240 VAC Allows the user to select the output voltage while on-line.
Output
frequency
Auto Auto
• 50 ± 3 Hz
• 50 ± 0.1 Hz
• 60 ± 3 Hz,
• 60 ± 0.1 Hz
Sets the allowable UPS output frequency. Whenever
possible, the output frequency tracks the input frequency.
Upper bypass
voltage
+10% of
output voltage
setting
+5%, +10%, +15%,
+20%
Maximum voltage that the UPS will pass to connected
equipment during internal bypass operation.
Lower bypass
voltage
-15% of output
voltage setting
-15%, -20%, -25%,
-30%
Minimum voltage that the UPS will pass to the connected
equipment during internal bypass operation.
Low battery
warning
2 minutes 2, 5, 7, 10, 12, 15, 18,
20 minutes.
The low battery warning beeps are continuous when two
minutes of run time remain.
Change the warning interval default to a higher setting if
the operating system requires a longer interval for
shutdown.
Minimum
Return Capacity
0% 0, 15, 25, 35, 50, 60,
75, 90%
After a low-battery shutdown, the batteries will be charged
to the specified percentage before the connected
equipment is powered.
Return Delay 0 seconds 0, 20, 60, 120,
240, 480, 720,
960 seconds
Set the return time delay (in seconds).
Shutdown Delay 20 second 0, 20, 60, 120,
240, 480, 720,
960 seconds
Set the interval between the time when the UPS receives a
shutdown command and the actual shutdown.
Audible Alarm Immediately Immediately,
30 second delay,
At Low Battery, Never
Mute ongoing alarms or disable all alarms permanently.
Auto Self Test Turn On +14 Days Never, Turn On Only,
Turn On +7 Days,
Turn On +14 Days
Set the interval at which the UPS will execute a self-test.
Redundancy
Power Alarm
Enable Enable, Disable Set the alarm if two UPS units are in parallel and the load
is higher than the output rating of one UPS.
External Battery
Packs
1 1, 2, 3, 4, 5,
6, 7, 8, 9
Set the number of connected external battery packs.
Ext Battery
Total Ah
80 Ah 0000-9999 Set the external battery capacity connected to UPS.
5/6 kVA=80 Ah; 8 kVA=140Ah; 10 kVA=180Ah
