Output Specications:
4-20 mA Output:
Input Voltage (Excitation): 9 VDC min (no load) to 28 VDC max
Input Current: 3-30 mA max
Signal Variance: +/-0.16 mA at set points
Wiring: 2 wire loop powered
Resolution: 14 bit
Protection: Reversed polarity
0-2 VDC Output:
Input Voltage (excitation): Battery powered
Output: Zero set point is +/-0.15 V with a 2 VDC span +/-0.02 VDC
Wiringt: 2 wire
Resolution: 14 bit
0-5 VDC Output:
Input Voltage (Excitation): 9 to 28 VDC
Input Current: 6 mA max
Output: 0-5 VDC / +/-0.5 VDC at set points
Wiring: Non-isolated 3 wire
Resolution: 14 bit
Protection: Reversed polarity
RS-485 Output:
Input Voltage (Excitation): 12 to 28 VDC
Input Current: 6 mA max
Output: Modbus RTU
Wiring: 4 wire
Protection: Reversed polarity
Trip Point Solid State Relay Outputs:
Maximum Switched Voltage: 120 V AC/DC
Maximum Switched Current: 120 mA
