PG7 Rev. A2, 07/16
16
Automation Products Group, Inc.
Full-Scale Range Adjust (RANGE):
Allows the user to adjust the reading at full-scale pressure. The reading can
be adjusted by +/-10% full-scale.
NOTE: The pressure reading must be within 5% of the full-scale value in
order to make Range adjustments. For example, a 1000 psi gauge would
need to be reading between 950 psi and 1050 psi in order to adjust the
Range feature. If the reading is not within 5% of full scale, NOAdJU (No
Adjustment) will be displayed when trying to adjust the Range.
Adjusting the Full-Scale Range:
Step 1: Ensure that the pressure reading is within 5% of full-scale.
Step 2: Press the On/O button to enter the main setup menu.
Step 3: Press (Z) to cycle through the options until AdVSET is displayed.
Step 4: Press (S) to access the Advanced Settings menu.
Step 5: Press (Z) to cycle through the options until RANGE is displayed.
Step 6: Press (S) to enter the Range adjust mode.
Step 7: Press (Z) to increase the reading, or press (S) to decrease the
reading.
Step 8: Press the On/O button to accept the adjusted reading and return
to the advanced setup menu.
Step 9: To exit the advanced setup menu, press (Z) until EXIT is displayed
and press (S) to exit to the main setup menu.
