APG PG-7 - Accessing the Mode Setting; Mode Definitions

PG7 Rev. A2, 07/16
6
Automation Products Group, Inc.
Accessing the Mode Setting:
Step 1: Simultaneously press and hold the On/O button and the (S)
button for approximately 3 seconds. This will bring up the 3 digit mode
number.
Step 2: Enter the desired mode number (see mode denitions below) by
using (Z) to change the value of the ashing digit, and (S) to advance to
the next digit.
Mode Denitions:
Mode 000: Full Access
- Provides access to all menu settings. If no buttons are pushed for
1 minute, the gauge will revert back to Mode 003 (factory default).
Mode 002: Limited Access
- Menu is locked
- (Z) button zeros the reading
- (S) cycles between the Max and Min readings
- On/O functions only on battery powered gauges
Mode 003: Factory Default
- Full access except Full Scale Calibration is locked
Mode 005: Locked Access
- All buttons locked except the on/o button on battery powered
gauges.
