APG PG-7 - Decimal Place

Rev. A2, 07/16 PG7
13
Automation Products Group, Inc.
Decimal Place (dEC PL):
The reading can be set to display in High Resolution (HI RES), Medium
Resolution (MEdRES) or Low Resolution (LO RES) mode. Switching between
resolutions will shift the displayed reading by one decimal place position.
NOTE: Gauges without a decimal place position will display a dummy zero
(or zeros) when the resolution is changed to medium or low.
Options: HI RES (high resolution), MEdRES (medium resolution) or LO RES
(low resolution)
Setting the Decimal Place feature:
Step 1: Press the On/O button to enter the main setup menu.
Step 2: Press (Z) to cycle through the options until AdVSET is displayed.
Step 3: Press (S) to enter the Advanced Settings menu.
Step 4: Press (Z) to cycle through the options until dEC PL is displayed.
Step 5: Press (S) to access the Decimal Place setting options.
Step 6: Press (Z) to cycle through the resolution settings.
Step 7: Press (S) to apply the displayed setting and return to advanced
setup menu.
Step 8: To exit the advanced setup menu, press (Z) until EXIT is displayed
and press (S) to exit to the main setup menu.
