E6 18 DTR.APC.APR.ALW.03(ENG)
Appendix MID
4. List of completeness
Together with APC-2000ALW transmitter user receives:
a) Product Certificate which is also a warranty;
b) Declaration of Conformity - on request;
c) User's Manual;
d) Copies of certificates - on request;
e) Calibration certificate - on request.
Items: b, c, d can be found at: www.aplisens.pl
5. APC-2000ALW for MID applications. Technical parameters
Transmitter supply (Usup) 13.5* ÷ 28V DC for Exi versions
13.5* ÷45V DC for Exd versions
Output signal 4÷20mA + HART
Ambient temperature -25 ÷ 55ºC
Relative humidity 10 ÷ 98% with condensation
Case protection ingress (according to EN 60529) IP 66
*
) Backlight setting
of indicates increases the minimum supply voltage by 3V. Display backlight is switched on
by the manufacturer at the order of the customer. In standard transmitters the backlight is turned off.
For the needs of clearing, in accordance with Directive 2014/32/EC, should be used one of the two
metrological checked transmitter output signals: digital HART signal or loop current signal.
Ingress case protection for gaseous fuels 1 and 2 family in accordance with EN 437 provides
a design of transmitter case and cable glands and plugs with seals of the HNBR, or TPE. In the
situation of its own cable glands and plugs you should use components dedicated to Ex zones, to
ensure: temperature, resistance to fuel gas families 1 and 2 and the above degree of protection. Can
be used cable glands with sealants such as TPE's for example: EX1100.20.110 AGRO.
5.1. Transmitters environmental parameters in the MID version
Products in this embodiment meets the following requirements; criteria by EN 12405-1:2005+A2:2010.
5.1.1. Electromagnetic Compatibility, immunity
Electrostatic Discharge (ESD):
EN 61000-4-2
Level 4,
Contact: ±8kV
Air: ±15kV
Criterion A,
Conducted Radio Frequency:
EN 61000-4-6
Level 3
0.15… 80MHz - 10V
Criterion A,
Radiated Electromagnetic Field:
EN 61000-4-3
Level 3
80 … 1 000MHz 10V/m
1 … 2.700GHz 1V/m
Criterion A,
Magnetic Field:
EN 61 000-4-8
Level 4
Electrical Fast Transient (Burst):
EN 61000-4-4
± 2kV, I/O
Electrical Slow Transient (Surges):
EN 61000-4-5
Level 3
5.1.2 Short drops in electrical supply
EN 61000-4-29
Level 1
5.1.3. Climatic Immunity
The transmitters can be installed in different climatic
conditions (see p.7 DTR.APC.APR.ALW.03(ENG)) in
environments of varying humidity, also in areas of
water vapour condensation.
Environment temperature:
EN 60068-2-1, EN 60068-2-2, EN60068-3-1
hot: T = 55ºC, R
H
= max 55%
cold: T = -25ºC,
Humid Permanent Heat:
EN60068-2-78
T=55ºC, R
H
=93%, 96h
Damp Heat Cycle:
EN 60068-2-30
(T = 22 ÷ 55ºC, R
H
= 80 ÷ 100%, 24h)x2
5.1.4. Mechanical Immunity
Shocks:
EN 60068-2-31, level 2
Vibrations in a wide band:
EN 60068-2-64, test Fh, level 2
i
i
