E6 26 DTR.APC.APR.ALW.03(ENG)
VII. FEATURES, INSTALLATION AND MAINTENANCE OF TRANSMITTERS
1. INTRODUCTION
1.1. This Manual is intended for users of APC-2000ALW smart pressure transmitters, APR-2000ALW,
APR-2200ALW, APR-2000GALW smart differential pressure transmitters, APR-2000YALW smart level probes,
APC-2000ALW/L smart level transmitters, APR-2200ALW/D smart density transmitters and their intrinsic-safety
versions, containing the data and guidelines necessary to understand the functioning of the transmitters and
how to operate them. It includes essential recommendations concerning installation and use, as well as
emergency procedures. The parameters and information specified for transmitters identified here as APC...,
APR... also apply to transmitters: APC-2000ALW, APR-2000ALW, APR-2200ALW, APR-2000GALW,
APR-2000YALW, APC-2000ALW/L, APR-2200ALW/D and their explosion-proof versions, as well as all the
variations differing by the type of the process terminals. Information on the transmitter sizes and the method of
installation apply to both, all versions of transmitters.
1.2. Technical data for the diaphragm seals and for the APC... and APR... transmitters are contained in
the catalogue cards “DIAPHRAGM SEALS”.
1.3. The transmitters comply with the requirements of EU directives as shown on the plate and with the relevant
Declaration of Conformity.
1.4. Additional data for APC-2000ALW, APR-2000ALW, APR-2200ALW, APR-2000GALW and
APR-2000YALW transmitters in intrinsic-safety Ex versions in accordance with ATEX directive is
contained in the appendix designed to DTR.APC.APR.ALW.03(ENG) Appendix Exi.ATEX and
in flame-proof Exd versions in the appendix designed to DTR.APC.APR.ALW.03(ENG) Appendix
Exd.ATEX.
During installation and use of the transmitters in Ex or Exd version in accordance with ATEX directive,
reference should be made to DTR.APC.APR.ALW.03(ENG) in conjunction with Appendix Exi.ATEX or
Appendix Exd.ATEX.
1.5. Additional data for APC-2000ALW, APR-2000ALW, APR-2200ALW, APR-2000GALW, APR-2200ALW/D
and APR-2000YALW transmitters in intrinsic-safety Ex versions in accordance with IECEX certificate is
contained in the appendix designed to DTR.APC.APR.ALW.03(ENG) Appendix Exi.IECEx and in flame-proof
Exd versions in the appendix designed to DTR.APC.APR.ALW.03(ENG) Appendix Exd.IECEx.
During installation and use of the transmitters in Ex or Exd version in accordance with IECEX certificate,
reference should be made to DTR.APC.APR.ALW.03(ENG) in conjunction with Appendix Exi.IECEx or
Appendix IECEX Exd.IECEx.
1.6. The pressure transmitters: APC-2000ALW, APR-2000ALW in realization for sea uses are complied with
Det Norske Veritas (DNV) Rules for Classification of Ships, High Speed & Light Craft and Det Norske Veritas'
Offshore Standards. Certificate No. A-13385 for application in following Location Classes: Temperature D,
Humidity: B, Vibrations: B, EMC: B, Enclosure: C.
1.7. The APC-2000ALW, APR-2000ALW transmitters are also made in a version which complies with the PED
Pressure Directive, meet the requirements for category IV, and then carry additional markings as in p. 4.3.
1.8. Essential data relating to installation of APC-2000ALW transmitters in accordance with MID Directive
contains MID Appendix.
1.9. Preparation of transmitters APC-2000ALW and APR-2000ALW type for operation in functional safety
systems is described in Appendix SIL
2.0. The transmitters in all versions comply the requirements of the RoHS Directive in accordance with
EN 50581: 2012.
2. USER MATERIALS
Transmitters are delivered in single and/or multiple packs.
Together with the transmitter are delivered:
a) Product certificate (which is also as the warranty card);
b) Declaration of conformity (on request);
c) Copy of certificate (on request);
d) User’s Manual numbered: DTR.APC.APR.ALW.03(ENG).
Items b), c), d) are available on www.aplisens.pl
